SMS commands for Concox IB-GT102 tracker

Introduction to SMS Commands for the Concox IB-GT102 Tracker

The Concox IB-GT102 tracker is a powerful tool for remote monitoring, offering a range of features that can be accessed through SMS commands. These commands are essential for users who want to configure or obtain information from the device quickly and conveniently. It is important to know when to use these commands: whether to change settings, request location information, or modify operational parameters.

Before getting started, it is crucial to ensure that you meet some prerequisites, such as having an active SIM card inserted in the device and familiarizing yourself with the security of the access password. Protecting the password is vital to prevent unauthorized access to your information and ensure the integrity of the tracked data. Proper management of security credentials can prevent future issues and ensure that your tracker operates effectively.

Using the Concox IB-GT102 with SMS commands is an efficient way to maximize the device's functionality. For an even more complete experience, consider integrating your operation with the Trackar platform, which offers a one-time payment solution, making it easier to track and manage your tracker optimally.

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This is essential when you want to reset the device's settings to an original state.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Set Time Zone

Adjust the device's time zone using the specific command. It is important that the time zone is correct for accurate tracking.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Set Carrier APN

Configuring the APN is crucial to ensure that the device connects correctly to the carrier's network. APN, username, and password information varies according to the chip provider and carrier used. Make sure to enter the correct data.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. Set DNS and Port

It is necessary to define the DNS server and port to ensure proper communication of the device with the tracking servers. Make sure that the details are correct.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Send Interval

The data send interval can be adjusted as needed. You can configure both the time in seconds and the angle in degrees for the device, allowing customization according to user needs.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

The external battery configuration must be performed to ensure that the device functions correctly, especially in situations where the main power source may be interrupted.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Global settings allow you to customize various aspects of the device, such as sending frequency and activating specific functions. It is crucial that these settings are adjusted according to the intended use.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activating the tow alarm is an additional safety measure that can alert the user in case of unauthorized movement of the vehicle.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

The command to request the device's position is essential to obtain real-time information about the vehicle's location.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

Special Commands

Below are special commands that can be used for various additional functions of the device.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
