Installation Manual for the Teltonika FMC130

The Teltonika FMC130 is a compact and efficient GPS tracking device designed to provide a robust solution for locating vehicles and assets. Proper installation of the FMC130 is crucial to ensure its full functionality and accuracy in data collection. In this manual, we will cover the essential aspects of physical installation, including choosing the ideal position for the GPS, power connections, inserting the SIM card, and post-installation verification procedures.

To optimize the performance of the Teltonika FMC130, it is important to position it in a location that minimizes obstructions and maximizes signal reception. The power supply should be securely connected, ensuring that the device receives the necessary energy to operate continuously. Additionally, inserting the SIM card should be done carefully, ensuring that it is properly installed to allow communication with the network.

After installation, verifying the systems and functions of the device is a fundamental step to confirm that everything is working properly. Follow the instructions carefully to ensure the effectiveness of your GPS tracker.

For efficient asset management, consider using the Trackar platform, which offers a tracking system with a one-time payment, further facilitating the monitoring and security of your vehicles.

SMS Commands

1. System Settings

To configure the Teltonika FMC130 tracker system, it is necessary to send a specific command that adjusts various operational parameters. This command sets essential configurations that influence the device's operation.

setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1

2. GPRS Configuration

The tracker needs to be connected to a GPRS server to send location data. Use the commands below to configure different servers, ensuring that the connection is always available.

setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1

3. Data Acquisition

To ensure effective data collection, it is necessary to configure acquisition parameters. These commands adjust the collection frequencies and the operational limits of the device, optimizing the performance of the tracker.

setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30

4. Accelerometer Features

The functions of the accelerometer are essential for detecting movement and impact. Adjusting these parameters allows the tracker to react appropriately to different situations, increasing the safety of the monitored vehicle.

setparam 11400:2;11500:2;11406:2

These settings are recommended for optimal operation of the tracker.

Special commands

5. Special Commands

Special commands are used for specific functions that may be necessary during the operation of the tracker. These commands allow restarting the device, obtaining modem information, locking/unlocking the vehicle, among others.

cpureset

getstatus

getgps

ggps

getimeiccid

getimsi

setdigout 1

setdigout 0

sdformat

deleterecords

defaultcfg
