Installation Manual for Teltonika FMC125
Installation Manual for the Teltonika FMC125
The Teltonika FMC125 is a compact and versatile GPS tracking device, ideal for real-time monitoring of vehicles and assets. To ensure optimized performance, it is essential to follow the appropriate installation guidelines. In this manual, we will address the physical installation of the FMC125, focusing on crucial aspects such as GPS positioning, power connection, SIM card insertion, and functionality verification.
The location of the device is essential to ensure adequate GPS signal reception. Ideally, it should be installed in a location with good visibility of the sky, avoiding obstructions that may affect tracking accuracy. The power supply must be connected correctly, adhering to the vehicle's standards to avoid damage to the device. Additionally, the SIM card insertion should be done carefully, ensuring it is properly positioned for effective communication.
Finally, it is imperative to conduct an initial verification to ensure that the Teltonika FMC125 is functioning as expected. Follow the instructions below to ensure a successful installation and enjoy all the benefits of real-time tracking. For a complete experience, try the Trackar platform with a one-time payment, optimizing the monitoring of your assets.
SMS Commands
1. System Configuration
To adjust the system settings of the Teltonika FMC125 tracker, it is necessary to use the appropriate commands. Below are the commands that should be sent to the device to configure the operating parameters.
setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1
2. GPRS Configuration - Server 01
The GPRS parameters need to be defined to ensure proper communication of the tracker. Below are the commands to configure the first GPRS server.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1
3. GPRS Configuration - Server 02
For the second GPRS server, use the commands below to ensure the device's connectivity.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
4. GPRS Configuration - Server 03
Finalize the GPRS configuration with the commands for the third server, ensuring the device's connectivity.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
5. Data Acquisition
To configure the data acquisition of the tracker, use the commands below, which define the collection parameters.
setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30
6. Accelerometer Characteristics
Configuring the characteristics of the accelerometer is essential for the proper functioning of the device. Use the commands below to define the parameters.
setparam 11400:2;11500:2;11406:2
These are the recommended settings for optimal tracker performance.
Special commands
Special Commands
Below are some special commands that can be used for specific operations on the device.
cpureset
getstatus
getgps
ggps
getimeiccid
getimsi
setdigout 1
setdigout 0
sdformat
deleterecords
defaultcfg
