Introduction to the Installation Manual for the Teltonika FMB920
The Teltonika FMB920 is a highly efficient GPS device designed to meet real-time tracking needs. To ensure the optimal functioning of your FMB920, it is essential to follow a physical installation process that includes the correct positioning of the device, power connection, SIM card insertion, and final verification. The choice of installation location is crucial, as it should be a spot that minimizes signal obstructions, typically in elevated areas or positions that favor communication with satellites.
The device's power supply should be secured, using a compatible power source to avoid damage to the equipment. The SIM card insertion should be done carefully, ensuring it is active and has an appropriate data plan for tracking. After installation, a complete verification is crucial to ensure that the FMB920 is operating correctly and sending location data.
To optimize your tracking experience, consider integrating your device with the Trackar platform, which offers a one-time payment and an intuitive interface to effectively manage your information. With the FMB920 and Trackar, you will have complete control over your tracking operations.
SMS Commands
1. System Configuration
To configure the Teltonika device's system, use the appropriate command to adjust the desired settings. The configurations can be adjusted according to the user's needs, ensuring that the tracker operates efficiently.
setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1
2. GPRS Configuration - Server 01
The tracker must be configured to connect to a specific GPRS server. It is essential that the server information is correct to ensure effective communication between the tracker and the tracking platform.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1
3. GPRS Configuration - Server 02
Just like the first server, a second GPRS server must be configured to ensure redundancy and continuity of communication. The information must be entered correctly to avoid connection failures.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
4. GPRS Configuration - Server 03
Similarly to the previous servers, the third server must be configured. This is crucial to ensure that the tracker maintains communication even if one of the servers fails.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
5. Data Acquisition
Data collection is essential for the operation of the tracker. Configure the data acquisition parameters to ensure that information is collected accurately and at appropriate intervals.
setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30
6. Accelerometer Settings
The functionalities of the accelerometer must be configured so that the device can respond to movements and changes in position. This is crucial for detecting security events.
setparam 11400:2;11500:2;11406:2
Special commands
Special Commands
Special commands allow additional interactions with the device, such as rebooting, locking, and formatting, providing greater control and maintenance of the tracker.
cpureset
getstatus
getgps
ggps
getimeiccid
getimsi
setdigout 1
setdigout 0
sdformat
deleterecords
defaultcfg
