Installation Manual for Teltonika FMB204
Introduction to the Installation Manual for the Teltonika FMB204
In this manual, we will cover the physical installation of the Teltonika FMB204 device, a high-performance GPS tracker that is ideal for various monitoring applications. The first crucial step in the installation is choosing the appropriate position for the GPS, which should be done carefully to ensure the best signal reception. It is recommended that the device be installed in a location that minimizes obstructions and interference.
Next, the power supply for the Teltonika FMB204 must be done correctly, ensuring that the device receives the necessary energy to operate continuously. Additionally, installing the SIM chip is a vital step, as it is responsible for the device's communication with the mobile network and, consequently, with the monitoring platform.
Finally, a thorough check of the device's operation is essential to ensure that everything is configured correctly. This includes testing connectivity and tracking accuracy. With the Teltonika FMB204 properly installed and configured, you will be ready to take advantage of all the functionalities it offers.
To further enhance the monitoring experience, consider using the Trackar platform, which offers an effective system with a one-time payment.
SMS Commands
1. System Configuration
To configure the Teltonika FMB204 tracker system, use the command below. This command adjusts various essential settings for the device's operation.
setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1
2. GPRS Configuration - Server 01
Configuring the GPRS server is essential to ensure communication between the tracker and the tracking platform. Use the following commands to establish the connection.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1
3. GPRS Configuration - Server 02
Continue configuring the second GPRS server to ensure redundancy and stability in communication. Execute the following commands.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
4. GPRS Configuration - Server 03
Complete the GPRS configuration with the third server. This will help maintain a stable and reliable connection.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
5. Data Acquisition
To ensure the correct data acquisition from the device, use the command below. This command adjusts the data collection parameters.
setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30
6. Accelerometer Settings
Configure the functionalities of the device's accelerometer with the command below. This will help in detecting movements and collecting relevant data.
setparam 11400:2;11500:2;11406:2
These settings are recommended for optimal device performance.
Special commands
7. Special Commands
The commands below allow special actions on the device, such as restarting, formatting the SD card, and restoring factory settings.
cpureset
getstatus
getgps
ggps
getimeiccid
getimsi
setdigout 1
setdigout 0
sdformat
deleterecords
defaultcfg
