Installation Manual for Teltonika FMB202
Introduction to the Installation Manual for the Teltonika FMB202
The Teltonika FMB202 is a compact and efficient GPS tracking device designed to provide a robust solution for locating vehicles and assets. In this manual, we will cover the fundamental aspects of the physical installation of the FMB202, ensuring that you can set up the device optimally for your use.
The correct positioning of the GPS is crucial to ensure tracking efficiency. It is recommended to install the FMB202 in a location that minimizes obstructions and maximizes sky visibility, allowing for better signal reception. Additionally, the device's power supply should be carried out according to the manufacturer's specifications, ensuring that the device operates continuously and reliably.
Another important point is the insertion of the SIM card, which should be done carefully to ensure the device's connectivity. After installation, it is essential to perform a check to confirm that all connections are secure and that the device is operating correctly.
For even more efficient management of your tracker, consider integrating the Teltonika FMB202 with the Trackar platform, which offers a one-time payment system, facilitating the monitoring and control of your assets in a practical and efficient manner.
SMS Commands
1. System Configuration
To configure the Teltonika FMB202 tracker system, it is necessary to send a specific command that adjusts various essential parameters. These parameters include frequency settings, operating mode, and other adjustments that ensure the proper functioning of the device.
setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1
2. GPRS Configuration - Server 01
The GPRS configuration is crucial for the tracker to connect to the network and send data. In this step, you will send commands that define the server and the necessary credentials for the connection.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1
3. GPRS Configuration - Server 02
We continue the GPRS configuration with more servers, allowing redundancy and greater reliability in the device's communication. Each command specifies a different server that can be used by the tracker.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
4. GPRS Configuration - Server 03
Finalizing the GPRS configuration, in this step you will add more servers that will ensure the communication of the tracker with the monitoring system.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
5. Data Acquisition
In this step, you will configure the data acquisition of the tracker, adjusting the parameters that determine the frequency of information collection and other related adjustments.
setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30
6. Accelerometer Features
Finally, you will adjust the characteristics of the accelerometer, which are important for detecting movements and impacts, thus ensuring better vehicle monitoring.
setparam 11400:2;11500:2;11406:2
Special commands
7. Special Commands
Special commands allow you to perform actions such as restarting the device, obtaining modem status, and formatting the SD card. They are essential for the maintenance and operation of the tracker.
cpureset
getstatus
getgps
ggps
getimeiccid
getimsi
setdigout 1
setdigout 0
sdformat
deleterecords
defaultcfg
