Installation Manual for Teltonika FMB120
Introduction to the Installation Manual for the Teltonika FMB120
The Teltonika FMB120 is a compact and versatile GPS tracking device, ideal for applications in vehicles and objects. This manual has been designed to guide you through the physical installation process of the device, addressing crucial aspects such as GPS positioning, power connection, SIM card insertion, and functionality verification.
To ensure optimized performance of the Teltonika FMB120, it is essential to choose a strategic location for the device installation, preferably in areas that provide good GPS signal reception, away from metallic obstructions. The power supply must be connected securely, respecting polarities, to avoid damage to the equipment. Additionally, the correct installation of the SIM card is essential to ensure communication between the device and the network.
After installation, it is recommended to perform a complete check to confirm that the Teltonika FMB120 is functioning correctly and transmitting data to the platform. By using the Trackar platform, you will have access to an efficient tracking system with a one-time payment, allowing you to monitor your assets conveniently and securely. Make the most of your device's features with the right support!
SMS Commands
1. System Configuration
To start the configuration of the Teltonika FMB120 device, it is necessary to define essential parameters that influence its operation. The following commands must be sent to the tracker to adjust its basic settings.
setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1
2. GPRS Configuration - Server 01
Establishing the GPRS connection is vital for the tracker to send location data. Use the commands below to configure the first server.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1
3. GPRS Configuration - Server 02
Continue the GPRS configuration with the second server. This ensures redundancy and stability in communication.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
4. GPRS Configuration - Server 03
Complete the GPRS configuration with the third server, ensuring maximum reliability in the tracker’s communication.
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1
setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1
5. Data Acquisition
The data acquisition configuration is essential for collecting accurate information from the device. Use the command below to adjust the collection parameters.
setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30
6. Accelerometer Features
The accelerometer features are essential for monitoring vehicle movement. Adjust the parameters as needed with the command below.
setparam 11400:2;11500:2;11406:2
Special commands
7. Special Commands
Below are special commands that can be used to manage the tracker quickly and efficiently.
cpureset
getstatus
getgps
ggps
getimeiccid
getimsi
setdigout 1
setdigout 0
sdformat
deleterecords
defaultcfg
These commands are useful for restarting, obtaining information, and managing the device effectively.
