Introduction to the MXT-141 Installation Manual
The installation manual for the MXT-141 GPS is an essential guide to ensure that your device operates optimally. In this document, we will cover the fundamental steps for physical installation, which include choosing the appropriate position for the GPS, providing power, installing the SIM card, and the necessary checks after installation.
The position of the GPS is crucial for effective tracking, as it should be chosen to maximize signal reception. The power supply must be done according to the specifications of the MXT-141, ensuring that the device receives the necessary energy to operate. Additionally, the installation of the SIM card should be done carefully following specific guidelines, ensuring that all components are correctly connected.
After installation, it is important to perform checks to confirm that the MXT-141 is functioning as expected. This includes checking connectivity and signal accuracy. By following these guidelines, you will ensure efficient performance of your device.
For an even more complete tracking experience, consider the Trackar platform, which offers a one-time payment for a robust and effective service.
SMS Commands
1. Carrier APN Configuration
It is essential to correctly configure the carrier's APN, as well as the username and password, since these details vary according to the chip supplier and the carrier used. Make sure to enter the correct information to ensure the device's connectivity.
0000,XXXXXXX,2,1,claro.com.br,claro,claro,central.trackar.com.br,5087,central.trackar.com.br,5087
0000,XXXXXXX,2,1,linksolutions.br,link,link,central.trackar.com.br,5087,central.trackar.com.br,5087
0000,XXXXXXX,2,1,smart.m2m.vivo.com.br,vivo,vivo,central.trackar.com.br,5087,central.trackar.com.br,5087
0000,XXXXXXX,2,1,transmeet.br,transmeet,transmeet,central.trackar.com.br,5087,central.trackar.com.br,5087
0000,XXXXXXX,2,1,voxter.br,algar,algar,central.trackar.com.br,5087,central.trackar.com.br,5087
0000,XXXXXXX,2,1,voxter.br,nlt,nlt,central.trackar.com.br,5087,central.trackar.com.br,5087
2. Transmission Interval Definition
The transmission interval can be adjusted to 60 seconds while the ignition is on and 55 minutes (3300 seconds) when the ignition is off. This setting is important to optimize battery consumption and device efficiency.
0000,XXXXXXX,4,60,3300,10,1,5,10
3. Position Request via GPRS
To request the device's position via GPRS, use the command below. This functionality allows you to obtain the real-time location of the tracker.
0000,XXXXXXX,7
5. SMS Commands
SMS commands allow you to perform various actions on the device. For the examples, the SMS password considered is 0000 and the module ID is represented by the last 7 digits of the tracker ID. See below the list of available codes.
0000,XXXXXXX,7
The available codes are: Code 1: Request position package via SMS; Code 2: Change GPRS connection settings; Code 3: Change SMS settings; Code 4: Change accelerometer settings; Code 5: Change output states; Code 6: Disable panic; Code 7: Request position via GPRS; Code 8: Enable or disable Speaker; Code 9: Reset Device; Code 10: Get ICC/ID of the Sim Card; Code 11: Request position via GPS; Code 12: Execute progressive lock; Code 13: Change the value of the Odometer; Code 14: Change the value of the Hourmeter.
Special commands
4. Special Commands
Below are the special commands that can be sent to lock or unlock the device. Use these commands with caution, ensuring that you are aware of the implications of each action.
0000,XXXXXXX,5,1,0,0
01A633000000002010211021B96904
0000,XXXXXXX,5,0,0,0
01A6330000000020102100987904
