MXT MXT-140 Installation Manual

Introduction to the MXT-140 Installation Manual

The installation manual for the MXT-140 GPS is an essential guide to ensure that your device operates optimally and efficiently. In this document, we will address the fundamental aspects of the physical installation of the equipment, including choosing the ideal position for the GPS, connecting to power, inserting the chip, and the final verification of operation.

Choosing the position of the GPS is crucial, as it directly impacts signal reception and the accuracy of information. It is recommended that the MXT-140 be installed in a location with minimal obstruction, such as on the vehicle's dashboard or in a suitable mount. The power supply should be connected carefully, following the manufacturer's guidelines to avoid damaging the device. Installing the chip is another important step; ensure that it is properly inserted and compatible with the device's system.

After installation, verifying the operation of the MXT-140 is an indispensable final step to ensure that all functions are operational. For efficient management and real-time monitoring, consider using the Trackar platform, which offers a one-time payment and a practical solution for tracking. Make the most of your MXT-140 with the best installation and management practices!

SMS Commands

1. Carrier APN Configuration

It is essential to correctly configure the carrier's APN, as well as the username and password, since this information may vary depending on the chip supplier and the carrier used. For each server, use the last 7 digits of the device ID, replacing 'XXXXXXX'.

0000,XXXXXXX,2,1,claro.com.br,claro,claro,central.trackar.com.br,5087,central.trackar.com.br,5087

0000,XXXXXXX,2,1,linksolutions.br,link,link,central.trackar.com.br,5087,central.trackar.com.br,5087

0000,XXXXXXX,2,1,smart.m2m.vivo.com.br,vivo,vivo,central.trackar.com.br,5087,central.trackar.com.br,5087

0000,XXXXXXX,2,1,transmeet.br,transmeet,transmeet,central.trackar.com.br,5087,central.trackar.com.br,5087

0000,XXXXXXX,2,1,voxter.br,algar,algar,central.trackar.com.br,5087,central.trackar.com.br,5087

0000,XXXXXXX,2,1,voxter.br,nlt,nlt,central.trackar.com.br,5087,central.trackar.com.br,5087

2. Transmission Interval Configuration

Set the transmission interval to 60 seconds with the ignition on and 55 minutes (3300 seconds) with the ignition off. The time can be adjusted as needed.

0000,XXXXXXX,4,60,3300,10,1,5,10

3. Position Request via GPRS

To request the position of the device via GPRS, use the corresponding command.

0000,XXXXXXX,7

Complete the recommended settings after this step.

Special commands

4. Special Commands

Here are the commands to lock and unlock the device.

0000,XXXXXXX,5,1,0,0

0000,XXXXXXX,5,0,0,0

Alternatively, you can use hexadecimal codes to lock and unlock.
