MT Topten MT35 Installation Manual

Introduction to the MT Topten MT35 Installation Manual

The MT Topten MT35 is a GPS tracking device designed to provide effective and accurate monitoring solutions. To ensure the optimal functioning of your device, it is essential to correctly follow the physical installation steps. In this manual, we will cover the main aspects to consider, such as choosing the appropriate position for the GPS, connecting the power supply, inserting the SIM card, and the necessary checks after installation.

The position of the GPS is crucial to ensure adequate signal reception. It is recommended to install it in locations that are not obstructed by metal or dense structures. The device's power supply should be handled carefully, ensuring that the power source is stable and compatible. Inserting the SIM card is a simple step, but it should be done with attention to avoid damaging the slot.

After installation, it is important to conduct a complete check to ensure that the MT Topten MT35 is operating correctly. Follow the guidelines in this manual and make the most of your tracker’s functionalities.

For an even more efficient tracking experience, consider the Trackar platform, which offers a one-time payment solution to manage all your devices in a practical and intuitive way.

SMS Commands

1. DNS and Port Configuration

To ensure communication of the tracker, it is essential to correctly configure the DNS servers. We recommend using the domain's DNS, as shown in the examples below:

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

APN settings, including username and password, must be adjusted according to the chip's carrier. Each provider may have different information, so it is important to verify the correct data before making the configuration.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Communication Time Configuration with Ignition On

The transmission interval can be configured in seconds. The default setting is 60 seconds, which determines the communication frequency while the ignition is on.

SET T3 FREQ=060

4. Communication Time Configuration with Ignition Off

The communication time can be adjusted in minutes. The default is 55 minutes, which defines the communication interval when the ignition is off.

SET HEARTBEAT=55

These settings are recommended to optimize the device's operation.

Special commands

5. Special Commands

Below are some special commands that can be used to manage the tracker.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
