MT Topten MT05 Installation Manual

Introduction to the MT Topten MT05 Installation Manual

Welcome to the installation manual for the MT Topten MT05, a GPS device designed to offer precision and reliability in vehicle location. In this guide, we will cover the main aspects of physical installation, including choosing the ideal position for the GPS, connecting the power supply, inserting the SIM card, and verifying the device's operation.

Proper installation of the MT Topten MT05 is crucial to ensure that the equipment functions effectively and that you can make the most of all its features. The position of the GPS should be carefully chosen to avoid obstructions and ensure the best signal reception. Additionally, the power supply must be connected according to the manufacturer's specifications, and the SIM card should be inserted correctly to ensure data communication occurs smoothly.

Last but not least, we will provide a step-by-step guide to verify the device's operation, ensuring that everything is functioning as expected.

For even more efficient management of your locations, consider the Trackar platform, which offers a one-time payment for access to advanced monitoring features. Let's get started!

SMS Commands

1. DNS and Port Configuration

It is essential to use a domain DNS to ensure the correct communication of the device. The recommended servers are as follows: for all cases, use the same address. Server 01, 02, and 03 should be configured to the same URL, which is central.trackar.com.br on port 6216.

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

The APN configuration is crucial and must be adjusted according to the carrier used. Each carrier may have a specific APN name, username, and password. Make sure to enter the correct information to ensure the device's connectivity.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Communication Time Adjustment with Ignition On

The communication time with the ignition on can be configured in seconds. The default interval of 60 seconds is recommended for regular data transmission. Adjust as needed to meet your requirements.

SET T3 FREQ=060

4. Communication Time Adjustment with Ignition Off

Similarly, the communication time with the ignition off is configurable in minutes. An interval of 55 minutes is suggested to save battery while the vehicle is not in use. Adjust as necessary.

SET HEARTBEAT=55

These settings are recommended to optimize the performance of the tracker.

Special commands

5. Special Commands

Special commands allow you to manage and obtain information from the device efficiently. Use them as needed to monitor and configure the tracker.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
