MT MT80 Installation Manual

Introduction to the MT MT80 Installation Manual

The MT MT80 device is an advanced solution for GPS tracking, designed to offer a practical and efficient installation. In this manual, we will cover the essential steps for the physical installation of your GPS, ensuring that you make the most of all the functionalities it offers.

The first step is to choose the appropriate position for the device. It is crucial to select a location that allows for optimal signal reception, avoiding areas with obstructions that may interfere with communication. After choosing the location, the next phase is connecting the power supply, which must be done carefully to ensure the safety and functionality of the system.

Additionally, installing the SIM chip is a fundamental step to enable communication of the MT MT80 with the tracking platform. It is important to verify that the chip is correctly inserted and that the data plan is active. Finally, we will conduct a functionality check to ensure that the device is operating according to specifications.

To maximize the efficiency of your tracker, consider using the Trackar platform, which offers an accessible system with a one-time payment, allowing complete control over your tracking activities. With the MT MT80 and Trackar, you will always be one step ahead.

SMS Commands

1. DNS and Port Configuration

For optimal configuration, it is recommended to use a domain DNS. You can set up to three servers with the same URL to ensure connectivity. Use the following command to configure:

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

It is essential that the APN, username, and password settings are adjusted according to the specifications of the chip provider and the carrier. Below are the commands that can be used:

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Communication Time with Ignition On

The communication time with the ignition on can be adjusted in seconds. The default transmission interval is 60 seconds. Use the command below to set the desired time:

SET T3 FREQ=060

4. Communication Time with Ignition Off

The communication interval with the ignition off can be adjusted in minutes, with 55 minutes being the default. To change this time, use the command below:

SET HEARTBEAT=55

Special commands

5. Special Commands

Here are some special commands that can be used to manage the device:

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
