MT Mini MT Installation Manual

Introduction to the MT Mini MT Installation Manual

The MT Mini MT GPS has been designed to offer a practical and efficient installation, providing real-time monitoring with high precision. This manual guides you through the physical installation of the device, addressing crucial aspects such as the ideal position for the GPS, connection to power, insertion of the SIM card, and verification of operation.

When choosing the GPS position, consider a location with good visibility of the sky, avoiding obstructions that may interfere with the signal. The power supply should be connected correctly to ensure that the device operates continuously and reliably. Don’t forget to insert a compatible SIM card that allows the necessary communication for data transmission. Finally, it is essential to conduct a complete verification after installation to ensure that the MT Mini MT is operating within specifications.

With the MT Mini MT, you will have more effective control over your assets and optimized fleet management. To further enhance your monitoring experience, consider the Trackar platform, which offers a one-time payment solution for tracking management.

Follow the instructions in this manual to ensure proper installation and enjoy all the benefits that the MT Mini MT can offer.

SMS Commands

1. DNS and Port Configuration

To ensure efficient communication, it is essential to correctly configure the server's DNS and port. Use the recommended domain to ensure proper connection.

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

The APN configuration is crucial and must be done according to the correct information provided by the chip carrier. Make sure to change the APN, username, and password as needed.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

The information may vary depending on the carrier used.

3. Communication Time with Ignition On

The transmission interval can be adjusted as needed. The time is defined in seconds, allowing you to control the frequency of location updates.

SET T3 FREQ=060

60 seconds is the default interval.

4. Communication Time with Ignition Off

Set the communication time when the ignition is off in minutes. This helps save battery and optimize communication.

SET HEARTBEAT=55

55 minutes is the default interval.

Special commands

5. Special Commands

Use special commands to efficiently manage and monitor the device.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT

These commands allow various functions, such as requesting information and controlling the device.
