MT i-Trac MT1 Installation Manual

Introduction to the MT i-Trac MT1 Installation Manual

Installing the MT i-Trac MT1 GPS tracker is a crucial step to ensure effective operation and accurate monitoring of your fleet or vehicle. This manual provides detailed guidance on the physical installation of the device, addressing essential aspects such as the ideal GPS position, power connection, SIM card insertion, and verification procedures after installation.

To achieve the best performance from the MT i-Trac MT1, it is vital to choose an installation location that minimizes obstructions and maximizes signal reception. Additionally, correctly installing the power source ensures that the device operates continuously and reliably. Proper insertion of the SIM card is equally important, as it guarantees communication between the tracker and the data network.

After installation, conducting a thorough check is essential to confirm that all components are functioning as expected. This process not only ensures the device's functionality but also provides peace of mind to the user.

To further enhance your monitoring experience, consider the Trackar platform, which offers a robust tracking system with a one-time payment. Explore the benefits of keeping your assets always under control!

SMS Commands

1. DNS and Port Configuration

To ensure proper communication of the tracker, it is essential to configure the DNS and port correctly. We recommend using the DNS of the specified domain. Use the following address for the servers: central.trackar.com.br on port 6216.

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

The APN settings, including username and password, must be adjusted according to the specifications of the chip supplier and the carrier. It is essential that this information is accurate to ensure device connectivity.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Communication Time with Ignition On

The communication time when the ignition is on can be adjusted in seconds. A 60-second interval is recommended to ensure efficient data transmission.

SET T3 FREQ=060

4. Communication Time with Ignition Off

The communication interval when the ignition is off should be set in minutes. An adjustment of 55 minutes is suggested to optimize battery consumption.

SET HEARTBEAT=55

These are the recommended settings to optimize the device's operation.

Special commands

5. Special Commands

Here are some special commands that can be used to effectively manage the device.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
