MT GMT100 Installation Manual

Introduction to the MT GMT100 Installation Manual

The MT GMT100 is a GPS tracking device designed to provide accuracy and reliability in your operations. This installation manual has been created to guide you in the proper setup of your device, ensuring that you can take full advantage of all its features.

The physical installation of the MT GMT100 is a crucial step for its full functionality. We will start by addressing the ideal position for the GPS installation, which should be chosen carefully to avoid obstructions that may interfere with signal reception. Next, we will discuss the power supply for the device, which should be done safely and efficiently. The installation of the SIM card is another important point, as it is responsible for the device's communication with the network. Last but not least, verifying the operation of the MT GMT100 is essential to ensure that all previous steps have been completed correctly.

By following this guide, you will be one step closer to integrating your device with the Trackar platform, which offers a one-time payment solution for real-time tracking management. Let's start the installation and make the most of your MT GMT100!

SMS Commands

2. Carrier APN Configuration

The APN configuration, along with the username and password, must be adjusted according to the carrier of the SIM card used. This information may vary, so it is essential that it is entered correctly.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Adjustment of Communication Time with Ignition On

The communication interval with the ignition on can be configured in seconds. The default value is 60 seconds, which determines the frequency of information transmission.

SET T3 FREQ=060

4. Adjustment of Communication Time with Ignition Off

For the ignition off, the interval is adjustable in minutes. The default is 55 minutes, which defines the time between transmissions when the vehicle is off.

SET HEARTBEAT=55

These settings are recommended to optimize the device's performance.

Special commands

1. DNS and Port Configuration

To ensure proper communication of the tracker, it is essential to correctly configure the DNS and port. Use the indicated domain for all servers, as listed below.

SET URL=central.trackar.com.br:6216

SET URL=central.trackar.com.br:6216 ### 5. Special Commands

Below are listed special commands that can be used to manage and obtain information from the tracking device.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
