MT Enfora MT4000 Installation Manual

Introduction to the MT Enfora MT4000 Installation Manual

The MT Enfora MT4000 is a GPS tracking device designed to offer precision and reliability in your monitoring applications. Proper physical installation is crucial to ensure the device's optimal performance. In this manual, you will find detailed guidance on the correct positioning of the GPS, connection to the power source, installation of the SIM card, and steps to verify the device's functionality.

To begin, it is important to select an appropriate location for the installation of the MT4000, ensuring that the GPS signal is not obstructed by metallic objects or other interferences. The power supply should be securely connected, adhering to the manufacturer's specifications to avoid damaging the device. The insertion of the SIM card should be done carefully, ensuring that it is well positioned and that the data plan is activated.

After installation, verifying the device's functionality is an essential step to ensure that all features are operating correctly. Follow the step-by-step instructions for an efficient and hassle-free installation.

Make the most of your MT Enfora MT4000 device by integrating it with the Trackar platform, which offers a monitoring solution with a one-time payment and no complications.

SMS Commands

1. DNS and Port Configuration

To ensure a stable connection, it is recommended to use a domain DNS. You should configure the server as follows: use the address central.trackar.com.br on port 6216 for all server instances.

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

It is essential that the APN, username, and password information are correctly entered, as they vary according to the carrier of the used SIM card. The following configurations are examples that should be adapted to your needs.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Adjust Communication Time with Ignition On

The communication time while the ignition is on can be adjusted in seconds. For example, a 60-second interval is a common setting for data transmission.

SET T3 FREQ=060

4. Adjust Communication Time with Ignition Off

The time for communication with the ignition off can be configured in minutes. A typical setting is 55 minutes, which defines the transmission interval in this state.

SET HEARTBEAT=55

These settings are recommended to optimize the device's performance.

Special commands

5. Special Commands

The following commands allow you to manage and obtain information from the device efficiently.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
