Installation manual for the Jimi JM-VL03

Introduction to the Installation Manual for the Jimi JM-VL03

The Jimi JM-VL03 is an advanced GPS tracking device designed to provide accuracy and reliability in locating vehicles and assets. The physical installation of this equipment is crucial to ensure its full functionality. In this section, we will cover fundamental aspects such as the ideal position for the GPS, connection to the power source, installation of the SIM card, and verification of the device's operation.

The position of the GPS should be carefully chosen, ensuring that it has a clear view of the sky to facilitate signal reception. Regarding power supply, it is essential to connect it to a stable power source to avoid operational failures. The installation of the SIM card should be done with care, ensuring that it is properly inserted into the appropriate slot. Finally, we recommend a verification test after installation to ensure that the Jimi JM-VL03 is operating correctly and transmitting the desired information.

To optimize your tracking experience, consider using the Trackar platform, which offers a one-time payment system, allowing for efficient and hassle-free management of your tracking devices. Proper installation of the Jimi JM-VL03 is the first step towards effective and secure monitoring.

SMS Commands

1. Time Zone Configuration

It is essential to adjust the device's time zone to ensure that location data is recorded correctly. Use the appropriate command to set the desired time zone.

GMT,W,0,0#

2. Update Time Adjustment

Set the time interval for location updates. The time can be adjusted between 5 and 18000 seconds, with the default values being 10 seconds for both movement and stop.

TIMER,60,3300#

3. External Voltage Activation

You can configure the external voltage that the device will use. The value must be adjusted between 5 and 3600, depending on the data upload needs.

ADT,ON,3600#

4. Server and Port Configuration

Configure the server and port for the tracker communication. It is important that the information is correct to ensure the connection.

SERVER,1,central.trackar.com.br,5023,0#

5. Carrier APN Configuration

The APN configuration is essential and must be done with the correct information for each carrier. This ensures that the device can connect to the network.

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,BRT.BR#

APN,CLARO.COM.BR#

APN,CONEXAO.GETRAK.COM.BR#

APN,ESEYE.COM#

APN,FEDERAL.BR#

APN,GPRS.OI.COM.BR#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,HINOVA.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,META.VIVO.COM.BR#

APN,OKTOR.BR#

APN,POWERTECH.ALGAR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,SS.CLARO.COM.BR#

APN,TIM.BR#

APN,TRANSMEET.BR#

APN,VIRTUEYES.COM.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,WAP.CTBC.BR#

APN,WL.VIVO.COM.BR#

APN,ZAP.VIVO.COM.BR#

6. GPRS Activation

Activate GPRS to allow data transmission. This step is essential for the tracker to send location information.

GPRSON,1#

7. Satellite Receiver Activation

Activate the satellite receiver for a period of 5 minutes to ensure that the device can locate its position.

GPSON#

Special commands

Special Commands

Here are some special commands that can be used to manage and query device settings.

PARAM#

SCXSZ#

GPRSSET#

STATUS#

ADT,OFF#

GPRSON,0#

GPRSON#

GPSDUP,A#

GPSDUP#

EXBATALM,ON#

EXBATALM,OFF#

RELAY,1#

RELAY,0#

ASETAPN,ON#

ASETAPN,OFF#

ANGLEREP,ON,20,2#

DISTANCE,300#

ICCID#

IMSI#

DOOR,0#

DOOR,1#

CLEAR#

WHERE#

URL#

POSITION#

VERSION#

RESET#

FACTORYALL#
