Jimi JM-VL02 Installation Manual

Introduction to the Jimi JM-VL02 Installation Manual

The Jimi JM-VL02 is a robust and reliable GPS tracking device designed to provide precise real-time monitoring. This manual aims to guide you in the physical installation of your device, addressing crucial aspects such as choosing the GPS position, electrical power supply, SIM card installation, and verifying the device's functionality.

To ensure optimal performance, it is essential to position the JM-VL02 in a location that minimizes obstructions and maximizes signal reception. Additionally, the connection to the power supply must be made carefully, ensuring that the device is always charged and ready to operate. The installation of the SIM card should follow the manufacturer's specifications to ensure effective communication with the network.

After installation, it is recommended to perform a complete check of the device to confirm that all functionalities are operating correctly. By following these guidelines, you will be able to enjoy all the advantages that the Jimi JM-VL02 offers.

For an even more comprehensive experience in monitoring your operations, consider the Trackar platform, which offers a one-time payment system and additional features to optimize your use of the GPS.

SMS Commands

1. Time Zone Configuration

It is essential to adjust the device's time zone to ensure that location information is accurate. To do this, use the appropriate command.

GMT,W,0,0#

2. Update Time Adjustment

The update time can be configured between 5 and 18000 seconds, with the factory default being 10 seconds for both on and off states. The transmission interval while the ignition is on or in motion is 60 seconds and, when off, is 3300 seconds.

TIMER,60,3300#

3. External Voltage Activation

The external voltage configuration allows you to set the amount of analog upload, which can vary from 5 to 3600. It is important to adjust according to the system's needs.

ADT,ON,3600#

4. DNS and Port Configuration

To connect the device to the server, it is necessary to configure the appropriate DNS and port. The settings must be entered as indicated, ensuring that the device connects correctly to the server.

SERVER,1,central.trackar.com.br,5023,0#

5. Carrier APN Configuration

It is crucial to update the APN, username, and password information according to the carrier of the used chip. Each carrier has specific settings that must be followed.

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,BRT.BR#

APN,CLARO.COM.BR#

APN,CONEXAO.GETRAK.COM.BR#

APN,ESEYE.COM#

APN,FEDERAL.BR#

APN,GPRS.OI.COM.BR#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,HINOVA.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,META.VIVO.COM.BR#

APN,OKTOR.BR#

APN,POWERTECH.ALGAR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,SS.CLARO.COM.BR#

APN,TIM.BR#

APN,TRANSMEET.BR#

APN,VIRTUEYES.COM.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,WAP.CTBC.BR#

APN,WL.VIVO.COM.BR#

APN,ZAP.VIVO.COM.BR#

6. GPRS Activation

To establish the data connection, it is necessary to activate the GPRS. This command ensures that the device can send and receive location information.

GPRSON,1#

7. Satellite Receiver Activation

To ensure accurate location, the satellite receiver must be activated for a period of 5 minutes. This allows the device to obtain a proper signal.

GPSON#

Special commands

Special Commands

These additional commands allow you to query and modify device settings conveniently.

PARAM#

SCXSZ#

GPRSSET#

STATUS#

ADT,OFF#

GPRSON,0#

GPRSON#

GPSDUP,A#

GPSDUP#

EXBATALM,ON#

EXBATALM,OFF#

RELAY,1#

RELAY,0#

ASETAPN,ON#

ASETAPN,OFF#

ANGLEREP,ON,20,2#

DISTANCE,300#

ICCID#

IMSI#

DOOR,0#

DOOR,1#

CLEAR#

WHERE#

URL#

POSITION#

VERSION#

RESET#

FACTORYALL#

These commands can be used to manage the tracker settings efficiently.
