Installation manual for Jimi JM-VL01

Introduction to the Jimi JM-VL01 Installation Manual

The Jimi JM-VL01 is a GPS tracking device designed to provide accuracy and reliability in your monitoring operations. In this manual, we will cover the essential steps for the physical installation of your GPS, ensuring that you make the most of its features.

The correct installation of the Jimi JM-VL01 involves choosing the ideal position for the device, which can directly influence signal quality. Additionally, it is crucial to connect the power supply properly, ensuring that the device operates without interruptions.

Another important aspect is the installation of the SIM card, which must be done carefully to avoid communication issues. Finally, do not forget to perform a complete check after installation, ensuring that all components are operating as expected.

By following these guidelines, you will be on the right path to a successful installation of the Jimi JM-VL01. To further optimize your tracking experience, consider using the Trackar platform, which offers a one-time payment solution for efficient and hassle-free monitoring.

SMS Commands

1. Time Zone Configuration

To ensure the tracker functions correctly, it is essential to set the time zone. Use the appropriate command to adjust the time according to your location.

GMT,W,0,0#

2. Update Interval Adjustment

The tracker’s update time can be adjusted between 5 and 18000 seconds. The factory default is 10 seconds for both ignition on and off. Adjust as needed to optimize tracking.

TIMER,60,3300#

3. External Voltage Activation

Activate the external voltage for continuous monitoring. The analog upload should be set between 5 and 3600 seconds, depending on the monitoring needs.

ADT,ON,3600#

4. Server Configuration

It is necessary to configure the server address and port to ensure that the tracker sends data correctly. Use the commands to set the desired server.

SERVER,1,central.trackar.com.br,5023,0#

5. APN Configuration

APN configuration is crucial for device connectivity. Ensure to enter the correct carrier information, as it varies by SIM card provider. Use the listed commands for each carrier.

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,BRT.BR#

APN,CLARO.COM.BR#

APN,CONEXAO.GETRAK.COM.BR#

APN,ESEYE.COM#

APN,FEDERAL.BR#

APN,GPRS.OI.COM.BR#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,HINOVA.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,META.VIVO.COM.BR#

APN,OKTOR.BR#

APN,POWERTECH.ALGAR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,SS.CLARO.COM.BR#

APN,TIM.BR#

APN,TRANSMEET.BR#

APN,VIRTUEYES.COM.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,WAP.CTBC.BR#

APN,WL.VIVO.COM.BR#

APN,ZAP.VIVO.COM.BR#

6. GPRS Activation

Activate GPRS to allow data communication from the tracker. This step is crucial to ensure that the device sends location information.

GPRSON,1#

7. Satellite Receiver Activation

To ensure the tracker can capture the location, activate the satellite receiver for a period of 5 minutes. This is essential for the initial operation of the device.

GPSON#

Special commands

Special Commands

Below are additional commands that can be used to manage and query device settings.

PARAM#

SCXSZ#

GPRSSET#

STATUS#

ADT,OFF#

GPRSON,0#

GPRSON#

GPSDUP,A#

GPSDUP#

EXBATALM,ON#

EXBATALM,OFF#

RELAY,1#

RELAY,0#

ASETAPN,ON#

ASETAPN,OFF#

ANGLEREP,ON,20,2#

DISTANCE,300#

ICCID#

IMSI#

DOOR,0#

DOOR,1#

CLEAR#

WHERE#

URL#

POSITION#

VERSION#

RESET#

FACTORYALL#
