CRX1 ET100 Installation Manual

Introduction to the CRX1 ET100 Installation Manual

Welcome to the installation manual for the CRX1 ET100 GPS device. This guide has been designed to assist you in the physical installation of your device, ensuring that all steps are carried out accurately for optimal performance.

When starting the installation, it is essential to choose the right position for the GPS. The location should allow for clear signal reception, avoiding obstructions that could compromise tracking effectiveness. Additionally, ensure that the device's power supply is connected correctly, following the provided guidelines to avoid damaging the equipment.

Do not forget to insert the communication chip correctly, ensuring that it is properly seated for uninterrupted operation. After the physical installation, it is advisable to perform a system check to confirm that all connections are secure and that the device is operating correctly.

Following these guidelines will ensure that the CRX1 ET100 operates efficiently and reliably. For even more effective tracking management, consider using the Trackar platform, which offers a one-time payment and access to advanced features for real-time monitoring. Make the most of your device!

SMS Commands

1. Time Zone Configuration

It is essential to adjust the device's time zone to ensure that location data is accurate. Use the appropriate command to set the GMT, as well as the hour, minute, and second settings.

GMT,W,0,0#

2. Update Time Adjustment

The location data update interval can be customized. It is important to correctly configure the transmission time while the vehicle is moving or stationary. The interval ranges from 5 seconds to 18000 seconds, with default values set.

TIMER,60,3300#

The X value represents the 60-second interval while the ignition is on, and Y represents 3300 seconds when the ignition is off.

3. Activate Voltage (External Voltage)

It is necessary to set the amount of analog upload to monitor the device's external voltage. This will help ensure that the tracker’s power supply is always within the required parameters.

ADT,ON,3600#

4. DNS and Port Configuration

Set the servers and ports that the tracker will use for communication. It is crucial that the information is correct to ensure connection with the monitoring platform.

SERVER,1,central.trackar.com.br,5023,0#

5. Carrier APN Configuration

Configuring the APN is essential to ensure that the tracker connects to the correct carrier network. You must enter the specific information for your carrier, as it may vary.

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,BRT.BR#

APN,CLARO.COM.BR#

APN,CONEXAO.GETRAK.COM.BR#

APN,ESEYE.COM#

APN,FEDERAL.BR#

APN,GPRS.OI.COM.BR#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,HINOVA.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,KORE.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,META.VIVO.COM.BR#

APN,OKTOR.BR#

APN,POWERTECH.ALGAR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,SS.CLARO.COM.BR#

APN,TIM.BR#

APN,TRANSMEET.BR#

APN,VIRTUEYES.COM.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,WAP.CTBC.BR#

APN,WL.VIVO.COM.BR#

APN,ZAP.VIVO.COM.BR#

6. Activate GPRS

Enable GPRS to ensure that the tracker can connect to the mobile data network. This is essential for the tracker’s operation.

GPRSON,1#

7. Activate Satellite Receiver

Activate the satellite receiver for a period of 5 minutes to ensure that the tracker can accurately locate the current position of the vehicle.

GPSON#

Special commands

Special Commands

These commands allow you to query and modify various settings of the tracking device, ensuring that you have full control over the tracker’s operation.

PARAM#

SCXSZ#

GPRSSET#

STATUS#

ADT,OFF#

GPRSON,1#

GPRSON,0#

GPRSON#

GPSDUP,A#

GPSDUP#

EXBATALM,ON#

EXBATALM,OFF#

RELAY,1#

RELAY,0#

ASETAPN,ON#

ASETAPN,OFF#

ANGLEREP,ON,30,3#

ANGLEREP#

ANGLEREP,OF#

DISTANCE,300#

ICCID#

IMSI#

DOOR,0#

DOOR,1#

CLEAR#

WHERE#

URL#

POSITION#

VERSION#

RESET#

FACTORY#

FACTORYALL#
