Installation Manual for Concox Start S-2011
Introduction to the Installation Manual for Concox Start S-2011
The Concox Start S-2011 is an advanced GPS tracking device designed to provide effective security and monitoring for vehicles. To ensure its optimal operation, the physical installation of the device must be carried out with attention to detail. In this manual, we will cover the fundamental aspects of installation, including the proper positioning of the GPS, connection to the power supply, insertion of the SIM card, and verification of the device's correct functioning.
Choosing the location for the installation of the Concox Start S-2011 is crucial, as it should be positioned to maximize GPS signal reception while being protected from interference and vandalism. The power supply should be connected safely, adhering to the manufacturer's specifications to avoid damage to the equipment. The insertion of the SIM card should be done carefully, ensuring it is correctly positioned for efficient communication.
After installation, it is essential to conduct a thorough check to ensure that all device functionalities are operating as expected. With the Concox Start S-2011 properly installed, you will be able to enjoy precise and reliable monitoring. For even more efficient control, check out the Trackar platform, which offers a one-time payment service for tracking management. With Trackar, you will have all the information at your fingertips.
SMS Commands
1. Time Zone Configuration
The first step is to set the device's time zone. This configuration is crucial to ensure that location data is recorded correctly according to local time.
GMT,W,0,0#
2. Update Time Adjustment
Set the tracker’s update interval. You can configure different times for when the vehicle is moving and when it is stationary. This helps optimize battery usage.
TIMER,20,20#
X represents the time in motion and Y the time at rest.
3. Angle Update
This setting allows the tracker to update its location based on a specific angle. Both the angle and detection time can be adjusted.
ANGLEREP,ON,30,2#
The tracker will update its position when it detects a change of 30 degrees within a 2-second interval.
4. Heartbeat Configuration
The heartbeat is a signal sent periodically to indicate that the device is active. You can adjust the sending interval according to the vehicle's ignition.
HB,1,55#
X is the interval with the ignition on and Y with the ignition off.
5. Server Configuration
In this step, you must configure the server address and port. It is important that this information is correct to ensure the tracker’s communication.
SERVER,1,central.trackar.com.br,5019,0#
Repeat the command for each additional server you want to configure.
6. APN Configuration
The APN configuration is vital for data connection. Enter the correct details according to the carrier of the chip used. Each carrier has its specific information.
APN,AGILIS.ALGAR.BR#
APN,ALLCOM.ALGAR.BR#
APN,ALLCOM.BR#
APN,ALLCOM.VIVO.COM.BR#
APN,CLARO.COM.BR#
APN,DATATEM.ALGAR.BR#
APN,ESEYE.COM#
APN,GPRS.OI.COM.BR,OI,OI#
APN,GPRS.TELEMIGCELULAR.COM.BR#
APN,IOT4U.BR#
APN,JBGPRS.BR#
APN,LINKSOLUTIONS.BR#
APN,M2DATA.ALGAR.BR#
APN,M2DATA.ARQIA.BR#
APN,M2DATA.VIVO.COM.BR#
APN,M2M.VODAFONE.BR#
APN,M2TRACK.BR#
APN,OKTOR.BR#
APN,SMART.M2M.VIVO.COM.BR#
APN,SS.ALGAR.BR#
APN,TIM.BR,TIM,TIM#
APN,TRANSMEET.BR#
APN,VIRTUEYES.VIVO.COM.BR#
APN,VOXTER.ALGAR.BR#
APN,VOXTER.BR#
APN,ZAP.VIVO.COM.BR#
APN.BRT.BR#
APN.META.VIVO.COM.BR#
Make sure the data is correct to avoid connection issues.
7. Force Position Sending
If necessary, you can force the tracker to send its current position every 5 minutes. This can be useful in emergency situations or for intensive monitoring.
LJDW#
Special commands
1. Special Commands
There are several special commands that can be used to manage the tracker more efficiently. These commands allow you to query settings, enable or disable specific functions, and even restart the device.
PARAM#
GPRSSET#
STATUS#
STA_SENDGPS,1#
STA_SENDGPS,0#
STA_SENDGPS#
SENDS,0#
SOS,A,XXXXXXXXXXX#
CENTER,A,XXXXXXXXXXX#
CENTER,D#
SOS,D,XXXXXXXXXXX#
RELAY,1#
RELAY,0#
ANGLEREP,ON,30,2#
ICCID#
HBT,1,55#
DW#
WHERE#
RESET#
FACTORY#
Use these commands with caution, as some actions may alter the device's settings.
