Concox SL22 Installation Manual

Introduction to the Concox SL22 Installation Manual

The Concox SL22 is a high-performance GPS tracking device designed to provide practical and efficient monitoring solutions. This manual provides detailed guidance on the physical installation of the equipment, covering crucial aspects such as the ideal position for the GPS, power supply needs, SIM chip installation, and functionality verification.

To ensure maximum performance of the Concox SL22, it is essential to choose an installation location that minimizes obstructions and maximizes signal reception. The power supply must be correctly connected to avoid operational failures. Additionally, the installation of the SIM chip requires special attention, ensuring that it is properly activated and compatible with the device.

After installation, verifying the GPS functionality is a fundamental step, allowing you to confirm that the device is operating as expected. Following these instructions will not only facilitate installation but also ensure that you make the most of the Concox SL22's features.

For even more efficient management, consider using the Trackar platform, which offers a one-time payment system for continuous and effective monitoring. Keep track of your assets with peace of mind and security!

SMS Commands

1. Time Zone Configuration

It is essential to set the device's time zone to ensure that location information is accurate. Use the appropriate command to adjust as needed.

GMT,W,0,0#

2. Update Time Adjustment

The tracker’s update interval can be adjusted in seconds. It is necessary to set two values: one for when the vehicle is in motion and another when it is stationary.

TIMER,20,20#

3. Angle-Based Update

Configure the location update based on a specific angle and detection time. This allows for a quicker response to changes in the vehicle's direction.

ANGLEREP,ON,30,2#

4. Heartbeat Configuration

The heartbeat interval can be adjusted to monitor the vehicle's activity. It is important to set different intervals for when the ignition is on and off.

HB,1,55#

5. Server Configuration

It is necessary to configure the server that the tracker will use to send data. This is done through commands that define the server and port.

SERVER,1,central.trackar.com.br,5023,0#

6. Carrier APN Configuration

APN, username, and password information must be adjusted according to the carrier of the chip used. This is crucial to ensure device connectivity.

APN,AGILIS.ALGAR.BR#

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,CLARO.COM.BR#

APN,DATATEM.ALGAR.BR#

APN,ESEYE.COM#

APN,GPRS.OI.COM.BR,OI,OI#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,OKTOR.BR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,TIM.BR,TIM,TIM#

APN,TRANSMEET.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,ZAP.VIVO.COM.BR#

APN.BRT.BR#

APN.META.VIVO.COM.BR#

7. Force Position Sending

If necessary, you can force the device to send its positions for a period of 5 minutes. This can be useful in emergency situations or intensive monitoring.

LJDW#

Special commands

Special Commands

These additional commands allow you to query and change specific settings of the tracker.

PARAM#

GPRSSET#

STATUS#

STA_SENDGPS,1#

STA_SENDGPS,0#

STA_SENDGPS#

SENDS,0#

SOS,A,XXXXXXXXXXX#

CENTER,A,XXXXXXXXXXX#

CENTER,D#

SOS,D,XXXXXXXXXXX#

RELAY,1#

RELAY,0#

ANGLEREP,ON,30,2#

ICCID#

HBT,1,55#

DW#

WHERE#

RESET#

FACTORY#

Remember that some commands may consume more vehicle battery.
