Installation Manual for Concox GV55VC

Installation Manual for the Concox GV55VC

The Concox GV55VC is a highly efficient GPS tracking device, ideal for monitoring vehicles and assets. To ensure proper operation, it is essential to carefully follow the physical installation steps. First, choose a strategic position for the GPS, preferably in a location where signal reception is optimized, such as under the dashboard or at the bottom of the vehicle, away from interference.

Next, it is crucial to connect the device's power supply. The GV55VC requires a stable power source, which can be obtained from the vehicle's battery. Ensure that the connections are firm and secure to avoid operational failures.

Do not forget to insert the SIM card into the device, which will enable communication with the network. Check that the SIM card is active and has an appropriate data plan. After connecting all components, it is advisable to perform a final check to ensure that the device is functioning correctly by testing signal reception and data transmission.

For an even more complete tracking experience, consider using the Trackar platform, which offers a one-time payment service, making it easier to manage and monitor your Concox GV55VC.

SMS Commands

1. Factory Reset

To restore the factory settings of the device, send the appropriate command. This is useful if the device is not functioning correctly or if you want to reconfigure it from scratch.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone to ensure that location data is accurate. This command allows you to set the local time according to your region.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Carrier APN Configuration

It is essential to enter the correct APN, username, and password information, as these vary according to the chip supplier and carrier. Below are the commands for different carriers.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

Make sure that the entered data is correct for the proper functioning of the device.

4. DNS and Port Configuration

Configure the DNS servers and port to ensure that the device can connect to the network correctly. It is important that this data is entered correctly for communication.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5004,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Set the data sending interval, which can be adjusted in seconds, and the movement angle. This is essential for the efficient communication of the device.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

Adjust the external battery settings to ensure that the device operates properly with the external power source.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

This command allows you to adjust the global settings of the device, ensuring that it operates according to your specific needs.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activate the tow alarm to increase the security of your vehicle. This feature is essential to prevent theft.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

To obtain the current location of the device, send this command. It is useful for monitoring the position in real-time.

AT+GTRTO=gv55,1,,0,,,,FFFF$

This command is essential for real-time tracking.

Special commands

10. Special Commands

Below are some special commands that can be used for specific functions on the device.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
