Concox GV55 Lite Installation Manual

Introduction to the Concox GV55 Lite Installation Manual

The Concox GV55 Lite is a GPS tracking device designed to provide an efficient and practical solution for monitoring vehicles and assets. In this manual, we will cover the essential steps for the physical installation of the device, including the ideal position for the GPS, connection to the power supply, insertion of the SIM card, and verification of the device's operation.

Proper installation of the Concox GV55 Lite is crucial to ensure tracking accuracy and the durability of the equipment. It is important to choose a location that not only protects the device from the elements but also optimizes GPS signal reception. Additionally, the connection to the power source should be done carefully, ensuring that the device receives continuous power.

Another fundamental aspect is the installation of the SIM card, which should be done carefully to avoid communication failures. After installation, a complete check will be performed to ensure that all functions of the Concox GV55 Lite are operating correctly.

To make the most of your device, consider using the Trackar platform, which offers an efficient tracking system with a one-time payment. Don’t miss the opportunity to maximize control over your assets!

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This procedure is useful for troubleshooting or starting a new configuration.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone to ensure that location data is accurate. This adjustment is essential for the proper functioning of the tracker.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Carrier APN Configuration

It is crucial to configure the APN, username, and password according to the carrier used. This information varies depending on the chip provider.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. DNS and Port Configuration

Set the DNS servers and port to ensure that the tracker connects correctly to the network. This is essential for data transmission.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5004,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Adjust the communication interval and detection angle. This allows the device to send data at a specific interval, saving battery and optimizing performance.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

Configure the external battery to ensure that the device operates correctly even when the main power source is turned off. This is important for safety and continuity of tracking.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Adjust the general settings of the device to customize its operation. These settings can affect the performance and usability of the tracker.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activate the tow alarm function to enhance vehicle security. This setting allows the device to detect unauthorized towing attempts.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

Send a command to obtain the current position of the device. This function is useful for real-time monitoring.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

1. Special Commands

Use special commands for specific device functions, such as restarting, clearing memory, and activating or deactivating detections.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
