Installation Manual for Concox GV500VC

Introduction to the Installation Manual for the Concox GV500VC

The Concox GV500VC is a GPS tracking device designed to provide precise and reliable monitoring. To ensure its optimal functioning, it is essential to correctly follow the physical installation steps. In this section, we will address crucial aspects such as the GPS position, power connection, SIM chip installation, and verification of the device's operation.

Choosing the installation location is essential to maximize GPS signal reception; it is recommended to select a high point free of obstructions. The device's power supply should be done according to the provided specifications, ensuring that the GV500VC operates without interruptions. The installation of the SIM chip should be carried out with care, ensuring that it is correctly positioned and that the data plan is active.

After installation, verifying the device's operation is a vital step to confirm that all connections are correct and that the tracker operates as expected. With these guidelines, you will be prepared to use the Concox GV500VC in your tracking applications.

For efficient management of your trackers, consider the Trackar platform, which offers a one-time payment and advanced monitoring functionalities.

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This is useful when you want to reconfigure the device or resolve operational issues.

AT+GTRTO=gv50,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone to ensure the reported time is correct. This is essential for accurate tracking.

AT+GTTMA=gv50,+,0,0,0,,,,,,FFFF$

3. Carrier APN Configuration

APN, username, and password settings must be correctly adjusted according to the carrier of the used SIM card. Each carrier has specific information that must be entered.

AT+GTBSI=gv50,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv50,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv50,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv50,datelo.com.br,claro,claro,,,,,FFFF$

AT+GTBSI=gv50,jbgprs.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv50,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv50,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv50,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv50,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv50,upchip.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv50,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv50,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. DNS and Port Configuration

Establish the DNS servers and the correct port to ensure proper communication of the device with the tracking platform. This is fundamental for the system's operation.

AT+GTSRI=gv50,4,,2,central.trackar.com.br,5004,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Set the communication interval for the device by adjusting the time and angle as necessary. This configuration is important to optimize battery consumption and the frequency of location updates.

AT+GTFRI=gv50,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

Adjust the external battery settings to ensure optimal performance and prolong the device's lifespan. This includes setting the capacity and operating parameters.

AT+GTEPS=gv50,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Make adjustments to the device's global settings to customize its operation according to your needs. These settings can affect the overall performance of the device.

AT+GTCFG=gv50,gv50,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activate the tow alarm to increase the security of your vehicle. This function alerts about unauthorized towing attempts.

AT+GTTOW=gv50,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

Send a command to request the current position of the device. This function is useful for monitoring the location in real time.

AT+GTRTO=gv50,1,,0,,,,FFFF$

Special commands

Special Commands

Use special commands to perform additional functions on the device, such as restarting, clearing memory, and activating specific functions.

AT+GTRTO=gv50,3,,,,,,FFFF$

AT+GTHMC=gv50,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv50,D,,,,,,FFFF$

AT+GTRTO=gv50,0,,0,,,,FFFF$

AT+GTRTO=gv50,7,,0,,,,FFFF$

AT+GTJDC=gv50,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv50,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv50,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv50,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
