Concox GV500MAP Installation Manual

Introduction to the Concox GV500MAP Installation Manual

The Concox GV500MAP is a robust and efficient device designed for real-time vehicle tracking. This installation manual provides essential guidelines to ensure that your tracker operates optimally.

When starting the installation, it is crucial to choose the correct position for the GPS. The location should be discreet and protected, ensuring the best satellite signal reception. The device's power supply should be safely connected to the vehicle's power source, while the installation of the SIM card requires special attention to ensure proper communication with the network.

After the physical installation, it is recommended to conduct a complete system check to confirm that all functionalities are operating as expected. The Concox GV500MAP, combined with the Trackar platform, offers a practical and affordable solution for monitoring, with a one-time payment, facilitating the management of your fleet or personal vehicle. Follow this manual for efficient installation and make the most of the benefits your device can offer.

SMS Commands

1. Factory Reset

To perform a factory reset of the device, use the appropriate command. This process will restore all settings to factory defaults, which is essential for troubleshooting or reconfiguring the device.

AT+GTRTO=gv50,4,,,,,,FFFF$

2. Time Zone Configuration

It is important to adjust the time zone to ensure that location data is accurate. The following command should be sent to correctly configure the device's time zone.

AT+GTTMA=gv50,+,0,0,0,,,,,,FFFF$

3. Carrier APN Configuration

Configuring the APN (Access Point Name) is crucial as it varies according to the carrier. Make sure to enter the correct information to ensure the device's connectivity.

AT+GTBSI=gv50,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv50,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv50,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv50,datelo.com.br,claro,claro,,,,,FFFF$

AT+GTBSI=gv50,jbgprs.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv50,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv50,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv50,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv50,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv50,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv50,upchip.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv50,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv50,voxter.algar.br,nlt,nlt,,,,,FFFF$

APN, username, and password information must be updated according to the carrier used.

4. DNS and Port Configuration

To ensure proper communication of the device, it is necessary to configure the DNS and port. Use the commands below to enter the server data.

AT+GTSRI=gv50,4,,2,central.trackar.com.br,5004,,,,0,0,0,1,,,FFFF$

5. Sending Interval Configuration

Adjusting the data sending interval is essential to optimize the device's communication. The following command allows you to configure the time and sending angle.

AT+GTFRI=gv50,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

The communication interval is set to 60 seconds with the ignition on and 3300 seconds with the ignition off.

6. External Battery Configuration

To ensure the proper functioning of the external battery, use the command below. This will help optimize the device's performance.

AT+GTEPS=gv50,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

The device's global settings can be adjusted to optimize its operation. Use the following command to apply the desired changes.

AT+GTCFG=gv50,gv50,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activating the tow alarm is essential for vehicle security. Use the command below to enable this function.

AT+GTTOW=gv50,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

To obtain the current location of the device, use the position request command. This command allows you to know where the device is located.

AT+GTRTO=gv50,1,,0,,,,FFFF$

This command is useful for real-time monitoring.

Special commands

1. Special Commands

There are special commands that can be used for specific functions of the device. Below are some of these commands.

AT+GTRTO=gv50,3,,,,,,FFFF$

AT+GTHMC=gv50,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv50,D,,,,,,FFFF$

AT+GTRTO=gv50,0,,0,,,,FFFF$

AT+GTRTO=gv50,7,,0,,,,FFFF$

AT+GTJDC=gv50,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv50,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv50,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv50,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
