Installation Manual for Concox GV300

Introduction to the Concox GV300 Installation Manual

The Concox GV300 is a robust and versatile GPS tracking device, ideal for monitoring vehicles and assets. This installation manual guides you through the physical installation process of the device, ensuring that you can make the most of its functionalities.

The correct positioning of the GPS is fundamental for effective performance. We recommend that the Concox GV300 be installed in a location that allows a clear view of the sky, avoiding obstructions that may interfere with signal reception.

The device's power supply must be done properly, ensuring that it is always on for continuous tracking. Additionally, installing the SIM card is a crucial step, as it enables communication between the device and the monitoring platform.

After installation, it is essential to perform a final check to ensure that all connections are secure and that the device is functioning correctly. Following these steps will ensure that you have an effective and uninterrupted tracking experience.

To optimize your tracking experience, consider using the Trackar platform, which offers a one-time payment and advanced functionalities for managing your assets.

SMS Commands

1. Factory Reset

To perform a factory reset of the device, use the appropriate command. This will restore all settings to factory defaults.

AT+GTRTO=gv300,4,,,,,,FFFF$

2. Time Zone Configuration

It is crucial to adjust the device's time zone to ensure that location data is accurate. Use the indicated command for this configuration.

AT+GTTMA=gv300,+,0,0,0,,,,,,FFFF$

3. Carrier APN Configuration

Configuring the APN is essential for the device's connectivity. The information must be updated according to the chip supplier and the carrier used.

AT+GTBSI=gv300,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv300,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv300,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv300,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv300,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv300,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv300,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv300,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv300,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv300,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv300,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv300,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv300,voxter.algar.br,nlt,nlt,,,,,FFFF$

APN, username, and password information varies by carrier.

4. DNS and Port Configuration

To ensure that the device connects correctly to the servers, it is necessary to configure the appropriate DNS addresses and ports. Use the commands below for this configuration.

AT+GTSRI=gv300,4,,2,central.trackar.com.br,5004,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Adjust the communication interval to optimize the performance of the tracker. It is possible to configure the sending time and the activation angle of the device.

AT+GTFRI=gv300,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

If using an external battery, it is important to configure the correct parameters to ensure that the device operates properly with the additional power source.

AT+GTEPS=gv300,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

The global settings of the device can be adjusted to customize the operation of the tracker. Use the indicated command to make these changes.

AT+GTCFG=gv300,gv300,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activate the tow alarm to increase the vehicle's security. Use the command below to enable this feature.

AT+GTTOW=gv300,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

To obtain the current location of the device, use the position request command. This can be useful for real-time monitoring.

AT+GTRTO=gv300,1,,0,,,,FFFF$

This is the end of the recommended settings.

Special commands

10. Special Commands

In addition to the standard settings, there are special commands that can be used to manage the device more efficiently.

AT+GTRTO=gv300,3,,,,,,FFFF$

AT+GTHMC=gv300,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv300,D,,,,,,FFFF$

AT+GTRTO=gv300,0,,0,,,,FFFF$

AT+GTRTO=gv300,7,,0,,,,FFFF$

AT+GTJDC=gv300,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv300,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv300,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv300,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
