Concox GT100 Installation Manual

Introduction to the Concox GT100 Installation Manual

The Concox GT100 is a robust GPS tracking device designed to provide an efficient and accurate monitoring experience. In this manual, we will cover the physical installation of the device, which includes the ideal GPS position, power supply, SIM card insertion, and procedures for verifying functionality.

To ensure optimal performance of the Concox GT100, it is crucial to position the device in a location that maximizes GPS signal reception, avoiding areas with significant obstructions. The power supply should be done according to the manufacturer's specifications, ensuring that the device operates continuously. The SIM card insertion must be done carefully, ensuring it is correctly positioned and activated for effective communication. Finally, verifying the GPS functionality is an essential step to confirm that the device is operating as expected.

Proper installation of the Concox GT100 not only optimizes the tracking of vehicles or assets but also provides peace of mind to the user. For those seeking an efficient tracking solution, the Trackar platform offers a one-time payment service, simplifying your monitoring experience. Take advantage of this opportunity and start tracking securely.

SMS Commands

1. Factory Reset

To restore the device to factory settings, send the appropriate command. This is useful for troubleshooting or starting the setup from scratch.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone using the specific command. This setting is important to ensure that location data is accurate in relation to local time.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Configure Carrier APN

It is crucial to update the APN, username, and password information, as these variables differ depending on the chip supplier and carrier. Below are the commands to configure the APN.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. Configure DNS and Port

Set the DNS servers and the port for device communication. This ensures that the tracker can properly connect to the monitoring platform.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Adjust the communication interval and the movement angle. The device can be configured to send data at different intervals depending on the ignition state and movement.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

Configure the device's external battery to ensure it operates efficiently, even in power outage situations.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Make adjustments to the global settings of the device, such as communication and security parameters. These settings help optimize the performance of the tracker.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activate the tow alarm function to protect the vehicle against theft attempts or unauthorized towing.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

Send a command to request the current position of the device. This is useful for real-time monitoring.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

1. Special Commands

Use special commands for additional functionalities of the device, such as restarting, clearing memory, or enabling/disabling detections.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
