Installation Manual for Concox GS503

The correct installation of the Concox GS503 GPS device is essential to ensure its full functionality and efficiency in location tracking. In this manual, we will cover the physical installation, which involves the correct positioning of the GPS, powering the device, inserting the SIM card, and verifying functionality after installation.

Start by choosing an appropriate location for the installation of the Concox GS503, where it can have good visibility of the sky for satellite signal reception. Powering should be done safely, using the recommended power source to avoid damaging the device. The insertion of the SIM card should be done carefully, ensuring it is well positioned and that the data plan is active. After installation, it is important to conduct a detailed check to ensure that the device is functioning correctly and sending data to the monitoring platform.

By following these steps, you can optimize the performance of your Concox GS503 and make the most of the functionalities offered. For even more efficient monitoring, consider using the Trackar platform, which offers a one-time payment and complete solutions for vehicle tracking.

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This procedure is essential when you want to start a new configuration or troubleshoot.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone to ensure that location data is accurate. The following command should be sent to make this configuration.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Configure Carrier APN

It is essential to update the APN, username, and password information according to the carrier of the used SIM card, as this information may vary. Use the commands listed below to configure.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. DNS and Port Configuration

To ensure proper communication of the device with the server, it is necessary to configure the DNS and the port. Use the following commands to set the correct parameters.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Adjust the communication interval of the device, which can be configured in seconds. It is possible to set different parameters for ignition on and off. Below are the commands for the configuration.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

If the device uses an external battery, it is important to configure it correctly. Use the command below to set the necessary parameters.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

The global settings of the device can be adjusted through the appropriate command. This allows you to customize the operation of the device according to your needs.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

To activate the device's tow alarm, use the indicated command. This function is important to protect the vehicle against theft.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

If you need to know the current location of the device, use the command to request the position. This is useful for real-time monitoring.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

1. Special Commands

There are special commands that allow you to perform specific actions on the device. Below are some commands that can be used for additional functions.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
