Concox G18 Installation Manual

Introduction to the Concox G18 Installation Manual

The Concox G18 GPS device is an effective solution for monitoring vehicles and assets, offering advanced features that ensure security and real-time tracking. This manual provides detailed guidelines for the physical installation of the equipment, addressing crucial aspects such as the ideal GPS position, power connection, SIM card insertion, and functionality verification of the device.

Choosing the location for installing the Concox G18 is essential to ensure tracking efficiency. It is recommended that the GPS be positioned to avoid obstructions that may interfere with communication with satellites. The power supply must be connected correctly to ensure the continuous operation of the device, while the installation of the SIM card should be done with attention to the manufacturer's specifications.

After installation, it is essential to perform a complete system check to ensure that the Concox G18 is operating correctly. By following this guide, you will be prepared to make the most of your tracker’s functionalities.

For even more efficient tracking, consider the Trackar platform, which offers a one-time payment system and robust resources for monitoring.

SMS Commands

1. Time Zone Configuration

To ensure that the tracker functions correctly, it is essential to set the time zone. This will allow the device to record the correct time when the information is collected.

GMT,W,0,0#

2. Update Interval

The tracker update can be adjusted in seconds. You can set a different interval for when the vehicle is in motion and when it is stationary. The default interval for movement is 20 seconds and for when it is stationary is also 20 seconds.

TIMER,20,20#

3. Angle Update

This setting allows the tracker to update its location based on a specific angle. For example, you can set it to update every 30 degrees and every 2 seconds.

ANGLEREP,ON,30,2#

4. Heartbeat

The heartbeat interval can be adjusted in minutes. This determines how often the tracker sends information while the vehicle is on or off. For example, you can set the device to send data every 1 minute with the ignition on and every 55 minutes with the ignition off.

HB,1,55#

5. Server Configuration

It is necessary to configure the server and port so that the tracker can connect to the tracking platform. The following commands configure the default server.

SERVER,1,central.trackar.com.br,5023,0#

6. Carrier APN Configuration

It is crucial that the APN, username, and password information are updated correctly, as they vary according to the chip provider and the carrier used. Below are the available APN commands.

APN,AGILIS.ALGAR.BR#

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,CLARO.COM.BR#

APN,DATATEM.ALGAR.BR#

APN,ESEYE.COM#

APN,GPRS.OI.COM.BR,OI,OI#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,OKTOR.BR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,TIM.BR,TIM,TIM#

APN,TRANSMEET.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,ZAP.VIVO.COM.BR#

APN.BRT.BR#

APN.META.VIVO.COM.BR#

7. Force Position Sending

If necessary, you can force the device to send its positions for 5 minutes, which can be useful in specific situations.

LJDW#

Special commands

1. Special Commands

The following special commands allow you to query settings, status, and other functionalities of the tracker. They are useful for managing the device effectively.

PARAM#

GPRSSET#

STATUS#

STA_SENDGPS,1#

STA_SENDGPS,0#

STA_SENDGPS#

SENDS,0#

SOS,A,XXXXXXXXXXX#

CENTER,A,XXXXXXXXXXX#

CENTER,D#

SOS,D,XXXXXXXXXXX#

RELAY,1#

RELAY,0#

ANGLEREP,ON,30,2#

ICCID#

HBT,1,55#

DW#

WHERE#

RESET#

FACTORY#
