Concox EV02 Installation Manual

Introduction to the Concox EV02 Installation Manual

The Concox EV02 is an advanced GPS tracking device designed to offer a simple and effective installation. In this manual, we will cover the essential steps for proper physical installation, ensuring that you can make the most of your tracker’s functionalities.

To start, it is crucial to choose the ideal position for the GPS to optimize signal reception and communication with the network. The device's power supply should be secured using an appropriate cable, and the installation of the SIM chip should follow the manufacturer's specifications to avoid connectivity issues.

After the physical setup, we recommend checking the operation of the Concox EV02, ensuring that all connections are secure and that the device is functioning correctly. By following these guidelines, you will ensure effective performance of your tracker, which is essential for real-time monitoring.

To further enhance your experience, consider using the Trackar platform, which offers a one-time payment and an intuitive interface to manage your tracking information practically and efficiently.

SMS Commands

1. Time Zone Configuration

To ensure the tracker functions correctly, it is essential to set the time zone. The command must be sent to adjust the device's time to GMT.

GMT,W,0,0#

2. Update Interval Adjustment

The update interval can be set in seconds. The first value (X) determines the transmission interval while the vehicle is in motion, and the second (Y) while it is stationary. This adjustment is crucial for optimizing data usage and tracker efficiency.

TIMER,20,20#

3. Angle-Based Update

The tracker can be configured to update its location based on a specific angle. For example, by setting an angle of 30 degrees and a detection time of 2 seconds, the tracker will update its position whenever these parameters are met.

ANGLEREP,ON,30,2#

4. Heartbeat Configuration

The heartbeat is a feature that allows adjustment of the tracker’s transmission interval. The first value indicates the time in minutes with the ignition on, and the second, the time with the ignition off. This helps save battery when the vehicle is not in use.

HB,1,55#

5. Server and DNS Configuration

For the tracker to function correctly, it is necessary to configure the server and port. The command should include the information of the server being used for tracking.

SERVER,1,central.trackar.com.br,5023,0#

6. Carrier APN Configuration

Configuring the APN is essential for the tracker to connect to the carrier's network. It is important to enter the correct APN, username, and password information, as they vary according to the chip provider and the carrier used.

APN,AGILIS.ALGAR.BR#

APN,ALLCOM.ALGAR.BR#

APN,ALLCOM.BR#

APN,ALLCOM.VIVO.COM.BR#

APN,CLARO.COM.BR#

APN,DATATEM.ALGAR.BR#

APN,ESEYE.COM#

APN,GPRS.OI.COM.BR,OI,OI#

APN,GPRS.TELEMIGCELULAR.COM.BR#

APN,IOT4U.BR#

APN,JBGPRS.BR#

APN,LINKSOLUTIONS.BR#

APN,M2DATA.ALGAR.BR#

APN,M2DATA.ARQIA.BR#

APN,M2DATA.VIVO.COM.BR#

APN,M2M.VODAFONE.BR#

APN,M2TRACK.BR#

APN,OKTOR.BR#

APN,SMART.M2M.VIVO.COM.BR#

APN,SS.ALGAR.BR#

APN,TIM.BR,TIM,TIM#

APN,TRANSMEET.BR#

APN,VIRTUEYES.VIVO.COM.BR#

APN,VOXTER.ALGAR.BR#

APN,VOXTER.BR#

APN,ZAP.VIVO.COM.BR#

APN.BRT.BR#

APN.META.VIVO.COM.BR#

7. Force Position Sending

If you need an immediate sending of positions, it is possible to force the device to send data for a period of 5 minutes. This command can be useful in emergency situations or when you want more frequent tracking temporarily.

LJDW#

Special commands

Special Commands

Special commands allow access to various functionalities of the tracker, such as querying settings, status, and manipulating the satellite receiver.

PARAM#

GPRSSET#

STATUS#

STA_SENDGPS,1#

STA_SENDGPS,0#

STA_SENDGPS#

SENDS,0#

SOS,A,XXXXXXXXXXX#

CENTER,A,XXXXXXXXXXX#

CENTER,D#

SOS,D,XXXXXXXXXXX#

RELAY,1#

RELAY,0#

ANGLEREP,ON,30,2#

ICCID#

HBT,1,55#

DW#

WHERE#

RESET#

FACTORY#

Attention: Some commands may consume more battery of the vehicle.
