Installation Manual for the Concox GK503

The Concox GK503 is an advanced GPS tracking device designed to provide an effective and reliable monitoring solution. In this manual, we will cover the physical installation of your device, ensuring that you can operate the GK503 with precision and efficiency.

Proper installation of the GPS is crucial for the optimal performance of the tracker. First, choose a suitable position for the device, preferably in a location that minimizes GPS signal obstruction. Next, it is important to securely connect the power supply, ensuring that the device receives the necessary energy to operate continuously.

Do not forget to insert a compatible SIM card, as it is essential for data transmission. After the physical installation, it is recommended to perform a functionality check of the device to ensure that all components are operating as expected.

With the Concox GK503, you have access to a range of features that enhance the security and efficiency of your monitoring. To complement your experience, consider using the Trackar platform, which offers a tracking system with a one-time payment, making it even easier to manage your device. Make the most of your Concox GK503!

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This is useful if you want to reconfigure the device from the beginning.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjusting the time zone is essential to ensure that location information is accurate. Use the command below to configure the time zone as needed.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. APN Settings

APN settings are crucial for the device's connectivity. APN, username, and password information must be adjusted according to the carrier of the SIM card used.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

Make sure that the information is correct for a successful connection.

4. DNS and Port Configuration

Configuring the DNS server and port is necessary to ensure that the device connects correctly to the network. Use the following commands to set the servers.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Sending Interval

The data sending interval can be adjusted as needed. It is important to set the time and communication angle to optimize the performance of the tracker.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

Configuring the external battery is essential to ensure the continuous operation of the tracker. Adjust the parameters as needed.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Global settings allow you to define general parameters for the device. It is important to review and adjust as necessary.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activating the tow alarm is an important feature for vehicle security. Use the command below to enable this function.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

To obtain the current location of the device, use the appropriate command. This can be useful in various situations.

AT+GTRTO=gv55,1,,0,,,,FFFF$

This command is essential for real-time monitoring.

Special commands

1. Special Commands

Special commands allow you to perform additional functions on the device. Use them as needed.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
