Coban TK104 Installation Manual

Introduction to the Coban TK104 Installation Manual

The Coban TK104 is a widely used GPS tracking device for monitoring vehicles and assets. To ensure proper and effective operation, it is crucial to follow the physical installation guidelines. This manual aims to guide you through the initial steps for installing your Coban TK104, addressing aspects such as choosing the GPS position, powering the device, inserting the SIM card, and verifying functionality.

The GPS position is essential to ensure a strong and accurate signal. It is recommended to install it in a location where there are no significant obstructions, such as metal or other large objects that may interfere with signal reception. The power supply should be connected correctly, ensuring that the device receives the necessary energy to operate continuously. The installation of the SIM card should be done carefully, ensuring that it is properly seated and active.

After installation, it is important to perform a check to confirm that the Coban TK104 is functioning as expected. Follow the steps outlined in this manual to maximize the effectiveness of your tracking system. For even more efficient management, consider the Trackar platform, which offers a tracking system with a one-time payment, ideal for enhancing the security and control of your assets.

SMS Commands

1. Start Configuration

To start using the tracker, you need to initiate the equipment configuration. This is done by sending a specific command to the device.

begin123456

2. Time Zone Configuration

Adjust the time zone of the tracker to ensure that location information is accurate. Use the appropriate command to set your time zone.

time zone123456 0

3. APN Configuration

It is crucial to correctly enter the APN, username, and password information, as these vary depending on the carrier of the SIM card used. Below are the commands for different APNs.

apn123456 algar.com.br

apn123456 allcom.br

apn123456 allcom.vivo.com.br

apn123456 brt.br

apn123456 claro.com.br

apn123456 conect.algar.br

apn123456 conexao.getrak.com.br

apn123456 core.br

apn123456 datatem.algar.br

apn123456 eseye.com

apn123456 federal.br

apn123456 gprs.amazoniacelular.com.br

apn123456 gprs.oi.com.br

apn123456 gprs.telemigcelular.com.br

apn123456 hinova.br

apn123456 jbgprs.br

apn123456 linksolutions.br

apn123456 m2data.algar.br

apn123456 m2data.arqia.br

apn123456 m2data.claro.com.br

apn123456 m2data.vivo.com.br

apn123456 m2m.vodafone.br

apn123456 m2track.br,vivo,vivo#

apn123456 meta.vivo.com.br

apn123456 mgdata.claro.com.br

apn123456 oktor.br

apn123456 sercomtel.com.br

apn123456 smart.m2m.vivo.com.br

apn123456 ss.algar.br

apn123456 ss.claro.com.br

apn123456 tim.br

apn123456 tmdata.tim.br

apn123456 transmeet.br

apn123456 upchip.br

apn123456 virtueyes.vivo.com.br

apn123456 voxter.algar.br

apn123456 voxter.br

apn123456 wap.ctbc.br

apn123456 wl.vivo.com.br

apn123456 y1.m2m.algar.com.br

apn123456 zap.vivo.com.br

4. DNS and Port Configuration

It is necessary to configure the DNS servers and port to ensure proper communication of the tracker with the server.

dns123456 central.trackar.com.br,5001

5. Tracking Mode

Activate the device's tracking mode to start monitoring the location in real-time.

tracker123456

6. Enable GPRS Transmission

For the tracker to send location data, it is necessary to enable transmission via GPRS.

gprs123456

7. Force GPRS Transmission

If necessary, you can force data transmission via GPRS to ensure that the information is sent immediately.

gprs123456 on

8. Smart Tracking Mode

Activate smart tracking mode, which saves data from the tracker’s SIM card. You can set a time interval for data transmission.

fix060s055m***n123456

9. Send Position by Angle

Adjust the angle at which the position will be sent. Remember that some versions of the tracker do not accept leading zeros.

angle123456 020

If your line has active SMS return and an error occurs, use the format without the leading zero, for example: angle123456 20.

10. Activate Fuel Sensor

Activate the fuel sensor status to improve the transmission of information about the tracker’s digital sensors.

protocol123456 18

11. Turn on Data Saving

The tracker will stop sending position if the vehicle remains stationary for more than 10 minutes. It will resume sending data as soon as the vehicle moves or an alarm is triggered.

less gprs123456 on

12. Turn off GPS

If the vehicle is not moving, GPS updates will be suspended. They will automatically resume when the vehicle starts moving again.

nosuppress123456

Special commands

1. Check Settings

This command allows you to check the current status of the tracker, including information about the battery, GPRS connection, GPS signal, and more.

check123456

The response will include details such as: POWER, Battery, GPRS, GPS, ACC, Door, and GSM signal. ### 2. Restart the Tracker

If necessary, you can restart the tracker by sending this command. This will turn it off and back on.

reset123456 ### 3. Continuous Tracking Mode

Activate continuous tracking mode, which allows data transmission every 30 seconds, without data saving.

fix030s***n123456 ### 4. Turn off Tracking Mode

Deactivate the current tracking mode using this command.

nofix123456 ### 5. Lock Vehicle

This command activates the vehicle lock function, preventing it from starting.

stop123456 ### 6. Unlock Vehicle

If the vehicle is locked, you can send this command to unlock it.

resume123456 ### 7. Activate Immediate Lock

Activate the immediate lock function of the vehicle with this command.

quickstop123456 ### 8. Deactivate Immediate Lock

Deactivate the immediate unlock function of the vehicle using this command.

noquickstop123456 ### 9. Check IMEI

This command allows you to check the IMEI number of the tracker.

imei123456 ### 10. Location Link

Receive a link with the current location of the tracker through this command.

localization123456 ### 11. Request Address

Send this command to request the address corresponding to specific latitude and longitude.

address123456 ### 12. Activate Key Alarm

Activate the tracker alarm that is triggered by the vehicle's key.

acc123456 ### 13. Deactivate Key Alarm

Deactivate the alarm triggered by the vehicle's key.

noacc123456 ### 14. TCP Mode

Activate TCP mode for data transmission using this command.

gprs123456,0,0 ### 15. UDP Mode

Activate UDP mode for data transmission using this command.

gprs123456,1,1 ### 16. Turn off Data Saving

Deactivate the tracker’s data saving with this command.

less gprs123456 off ### 17. Enter Sleep Mode

Put the tracker in sleep mode when there is no movement, using this command.

sleep123456 shock ### 18. Turn off Sleep Mode

Deactivate the tracker’s sleep mode so that it returns to normal operation.

nosleep123456 ### 19. Activate Door Sensor

Activate the tracker’s door sensor to monitor the opening and closing of doors.

arm123456 ### 20. Activate Low Battery Alarm

Activate the alarm that indicates the tracker’s battery is low.

lowbattery123456 on ### 21. Deactivate Low Battery Alarm

Deactivate the low battery alarm with this command.

lowbattery123456 off ### 22. Activate Power Cut Alarm

Activate the alarm that is triggered when there is a power cut in the tracker.

extpower123456 on ### 23. Deactivate Power Cut Alarm

Deactivate the power cut alarm using this command.

extpower123456 off ### 24. Clear Internal Memory

This command allows you to clear the internal memory of the tracker.

clear123456 ### 25. Send Position by Distance

Set the distance in meters for sending the tracker’s position. The number must be 4 digits.

distance123456 0050

This command overrides the smart tracking mode. ### 26. Change Default Password

If you want to change the default password of the tracker, use this command, replacing the old password with the new one.

password + senha_antiga + espaço + senha_nova

Example: password123456 999999 ### 27. Reset Password

If you have forgotten the password, you can reset it using this command.

reset password

The GSM signal level must be greater than 10 to connect to the server.
