Coban TK06A Installation Manual
Introduction to the Coban TK06A Installation Manual
The Coban TK06A is a GPS tracking device designed to provide accurate and reliable location. The physical installation of this device is a crucial step to ensure its optimal performance. In this manual, we will cover the main aspects of the installation, including GPS positioning, power supply, SIM chip, and verification of the device's operation.
For effective installation, it is important to choose a location that provides good signal reception. The GPS positioning should be done in an area with minimal obstruction, avoiding metallic materials that may interfere with communication. The device's power supply should be connected correctly, ensuring that the Coban TK06A receives the necessary energy to operate without interruptions.
Additionally, inserting the SIM chip is essential, as it allows the device to connect to the mobile network to send location data. After installation, it is recommended to perform a complete check to ensure that all functions of the device are operating as expected.
Make the most of your Coban TK06A and consider using the Trackar platform, which offers an efficient tracking system with a one-time payment. Ensure the security and monitoring of your assets with ease!
SMS Commands
1. Start Equipment Setup
To begin the configuration of your tracker, use the activation command. This step is essential for the device to operate correctly.
begin123456
2. Set Time Zone
It is necessary to adjust the time zone of the tracker so that it can accurately record the location. Use the appropriate command with the time difference from GMT.
time zone123456 0
3. Configure Carrier APN
Configuring the APN is crucial, as it varies by carrier. Make sure to enter the correct information to ensure device connectivity.
apn123456 allcom.br
apn123456 linksolutions.br
apn123456 m2data.arqia.br
apn123456 smart.m2m.vivo.com.br
apn123456 tim.br
apn123456 transmeet.br
apn123456 virtueyes.com.br
apn123456 zap.vivo.com.br
APN, username, and password information must be updated according to the carrier used.
4. Set DNS and Port
It is important to define the DNS servers and the port that the tracker will use to connect to the network. This information should be provided by your carrier.
Server 01, Server 02, Server 03: information to be filled in.
5. Activate Vibration Alarm
This command activates the vibration alarm, which alerts about unexpected movements of the tracker. It is an important feature for security.
shock123456
6. Activate Tracking
For the tracker to start monitoring the location, it is necessary to activate the tracking function. This will allow you to receive location updates.
tracker123456
7. Activate GPRS Transmission
Activating GPRS is essential for the tracker to send location data to the server. Without this configuration, tracking will not work.
gprs123456
8. Set Transmission Time
Adjust the time interval between data transmissions. The default is 60 seconds when the device is in motion, but it can be changed as needed.
upload123456 060
The transmission time is adjustable.
9. Sleep Mode by Sensor
The tracker can enter power-saving mode after 5 minutes of inactivity. It will be activated again by any movement or vibration.
sleep123456 shock
The wake-up mode can be activated by movement, SMS, or call.
Special commands
Special Commands
Below are additional commands that can be used for specific functions of the tracker.
G123456#
where
gprs123456 0
sensitivity123456 + selecionar número 1, 2 ou 3!
check123456
speed123456 080
nospeed123456
shock123456
noshock123456
lowbatsms123456 on
sleep123456 time
sleep123456 shock
sleep123456 off
imei123456
reset123456
