Coban TK-102B Installation Manual

Introduction to the Coban TK-102B Installation Manual

The Coban TK-102B is a GPS tracking device designed to provide security and real-time monitoring. In this manual, we will cover the physical installation of the device, addressing essential aspects such as GPS positioning, power connections, SIM card installation, and verifying the device's functionality.

The correct positioning of the GPS is fundamental to ensure the effectiveness of tracking. The device should be installed in a location that minimizes obstructions and maximizes signal reception. Additionally, the power supply must be connected properly to ensure that the device operates without interruptions.

Installing the SIM card is another crucial step; make sure the card is properly inserted and that the data plan is active for tracking to function correctly. After completing the installation, it is important to perform a check to ensure that all functions of the Coban TK-102B are operational.

For efficient and affordable tracking, consider using the Trackar platform, which offers a one-time payment model, with no monthly fees. Take advantage of this practical and effective solution to securely monitor your assets!

SMS Commands

1. Start of Configuration

To begin configuring the Coban TK-102B tracker, send the initial command that activates the device. This step is essential to ensure that all subsequent settings are applied correctly.

begin123456

2. Time Zone Configuration

Adjust the time zone of the tracker so that it sends accurate location information. Use the appropriate command, replacing '0' with your local time zone.

time zone123456 0

3. APN Configuration

Configuring the APN is essential for the tracker to connect to the carrier's network. The information varies by provider, so it is important to use the correct data.

apn123456 algar.com.br

apn123456 allcom.br

apn123456 allcom.vivo.com.br

apn123456 brt.br

apn123456 claro.com.br

apn123456 conect.algar.br

apn123456 conexao.getrak.com.br

apn123456 core.br

apn123456 datatem.algar.br

apn123456 eseye.com

apn123456 federal.br

apn123456 gprs.amazoniacelular.com.br

apn123456 gprs.oi.com.br

apn123456 gprs.telemigcelular.com.br

apn123456 hinova.br

apn123456 jbgprs.br

apn123456 linksolutions.br

apn123456 m2data.algar.br

apn123456 m2data.arqia.br

apn123456 m2data.claro.com.br

apn123456 m2data.vivo.com.br

apn123456 m2m.vodafone.br

apn123456 m2track.br,vivo,vivo#

apn123456 meta.vivo.com.br

apn123456 mgdata.claro.com.br

apn123456 oktor.br

apn123456 sercomtel.com.br

apn123456 smart.m2m.vivo.com.br

apn123456 ss.algar.br

apn123456 ss.claro.com.br

apn123456 tim.br

apn123456 tmdata.tim.br

apn123456 transmeet.br

apn123456 upchip.br

apn123456 virtueyes.vivo.com.br

apn123456 voxter.algar.br

apn123456 voxter.br

apn123456 wap.ctbc.br

apn123456 wl.vivo.com.br

apn123456 y1.m2m.algar.com.br

apn123456 zap.vivo.com.br

Make sure that the APN data is correct before sending the commands.

4. DNS and Port Configuration

It is necessary to configure the DNS servers and the port that the tracker will use to connect to the tracking server. The following commands must be sent to ensure correct communication.

dns123456 central.trackar.com.br,5001

5. Tracking Mode Activation

Activate the device's tracking mode so that it starts sending location information. This step is crucial for the tracker to function.

tracker123456

6. GPRS Transmission Enablement

For the tracker to send location data, GPRS transmission must be enabled. Send the corresponding command to activate this function.

gprs123456

7. Force GPRS Transmission

If necessary, you can force data transmission via GPRS. This ensures that the tracker sends information even under unstable network conditions.

gprs123456 on

8. Smart Tracking Mode Configuration

The smart tracking mode saves data from the tracker chip by adjusting the transmission interval. Configure the transmission times as needed.

fix060s055m***n123456

The smart mode sets a time of 60 seconds with the vehicle on and 55 minutes when off.

9. Position Sending Angle Configuration

Adjust the angle for position sending. The value can be changed as needed, but some versions of the device do not accept leading zeros.

angle123456 020

If you receive a format error, use a 3-digit number without leading zeros.

10. Fuel Sensor Activation

Activate the fuel sensor to improve the status transmission of digital sensors. This will help monitor the vehicle's fuel level.

protocol123456 18

11. Data Saving Activation

When the vehicle is stopped for more than 10 minutes, the tracker stops sending data. It resumes transmission as soon as the vehicle moves or an alarm is triggered.

less gprs123456 on

12. GPS Shutdown

Deactivate the GPS to avoid updates when the vehicle is not in motion. The tracker resumes updates automatically when it is moved again.

nosuppress123456

Special commands

13. Special Commands

Here are some special commands that can be used to query settings or perform specific actions.

check123456

reset123456

fix030s***n123456

nofix123456

stop123456

resume123456

quickstop123456

noquickstop123456

imei123456

localization123456

address123456

acc123456

noacc123456

gprs123456,0,0

gprs123456,1,1

less gprs123456 off

sleep123456 shock

nosleep123456

arm123456

lowbattery123456 on

lowbattery123456 off

extpower123456 on

extpower123456 off

clear123456

distance123456 0050

password + senha_antiga + espaço + senha_nova

resetar senha

Make sure that the GSM signal is above 10 for a stable connection.
