Coban LK800 Installation Manual

Introduction to the Coban LK800 Installation Manual

The Coban LK800 is a GPS tracking device designed to provide accuracy and reliability in monitoring vehicles and assets. In this manual, we will cover the physical installation of the device, ensuring that you have a clear understanding of the ideal position for the GPS, the necessary power supply, the insertion of the SIM chip, and the steps for a successful functionality check.

Choosing the correct position for the device is crucial, as it directly influences the quality of the GPS signal. Ensure that the chosen location is free from obstructions that may interfere with signal reception. Regarding power supply, the LK800 should be connected to a stable power source to ensure its continuous performance. The installation of the SIM chip must be done carefully, ensuring that it is correctly positioned and activated for effective communication.

Finally, we will conduct a verification process to confirm that everything is functioning properly. The Coban LK800 is an excellent choice for those seeking security and real-time monitoring.

To further optimize your tracking experience, consider the Trackar platform, which offers a one-time payment system, facilitating the management of your tracking needs.

SMS Commands

1. Start of Equipment Configuration

To begin the configuration of the LK800 tracker, it is necessary to send the initial command. This command activates the device and allows you to proceed with the following configurations.

begin123456

2. Time Zone Configuration

It is important to adjust the time zone of the tracker to ensure that location data is accurate. Use the appropriate command to set the desired time zone.

time zone123456 0

3. Carrier APN Configuration

The APN (Access Point Name) configuration must be done carefully, as each carrier has specific information. Make sure to enter the correct data for the tracker to function properly.

apn,m2track.br,vivo,vivo#

apn123456 allcom.br

apn123456 allcom.vivo.com.br

apn123456 brt.br

apn123456 claro.com.br

apn123456 datatem.algar.br

apn123456 eseye.com

apn123456 gprs.amazoniacelular.com.br

apn123456 gprs.oi.com.br

apn123456 gprs.telemigcelular.com.br

apn123456 linksolutions.br

apn123456 m2data.algar.br

apn123456 m2data.arqia.br

apn123456 m2data.vivo.com.br

apn123456 m2m.vodafone.br

apn123456 m2mprepgago.br arqia arqia

apn123456 meta.vivo.com.br meta meta

apn123456 oktor.br

apn123456 sercomtel.com.br

apn123456 smart.m2m.vivo.com.br

apn123456 ss.algar.br

apn123456 tim.br

apn123456 tmdata.tim.br

apn123456 transmeet.br

apn123456 virtueyes.vivo.com.br

apn123456 voxter.algar.br

apn123456 voxter.br

apn123456 wap.ctbc.com.br

apn123456 wl.vivo.com.br

apn123456 y1.m2m.algar.com.br

apn123456 zap.vivo.com.br

APN information varies according to the carrier used.

4. DNS and Port Configuration

Set the DNS servers and the port that the tracker will use to connect to the tracking server. It is essential to ensure that this data is correct for the proper functioning of the device.

SZCS,123456,DOMAIN=central.trackar.com.br:6013

5. Enable GPRS Transmission

Activate data transmission via GPRS so that the tracker can send location and status information. This step is crucial for the functioning of the device.

gprs123456

6. Activate Tracking Mode

Enable the device's tracking mode, allowing it to start sending real-time location data. It is important that this setting is active for continuous monitoring.

tracker123456

7. Transmission Time Configuration

It is possible to adjust the time interval at which the tracker will send location data. The default time is 60 seconds, but it can be changed according to your needs.

upload123456 60

8. Activate Vibration Alarm

Configure the vibration alarm so that the tracker can detect sudden movements and trigger alerts. This function is useful for equipment security.

shock123456

9. Sleep Mode by Sensor

Activate the energy-saving mode, where the tracker enters sleep mode after five minutes without movement. Any vibration or movement will cause it to return to an active state.

sleep123456 shock

The tracker can be activated again by movement, SMS, or call.

Special commands

10. Special Commands

Here are some useful commands that can be used to manage and obtain information from the tracker quickly.

G123456

where

check123456

(s42,1234)

status

Param1

Param2

sos

sleep123456 10

sleep123456 shock

nosleep12345

shock123456

noshock123456

pwr1

pwr0

555

666

imei123456

rst

format
