Coban LK209C Installation Manual

The Coban LK209C is a versatile and efficient GPS tracking device, ideal for monitoring vehicles and assets. This manual aims to provide clear guidance on the physical installation of the device, addressing crucial aspects such as GPS positioning, power supply, SIM card insertion, and functionality verification.

Correct installation of the Coban LK209C is essential to ensure its optimal performance. The GPS positioning should be done in a location with good visibility of the sky, avoiding obstructions that may compromise signal reception. The device's power supply should be done safely, using the appropriate power source to avoid damage to the equipment. Additionally, the installation of the SIM card should be carried out carefully, ensuring that it is properly seated and enabled for data transmission.

After installation, it is essential to conduct a complete verification to ensure that all functions of the Coban LK209C are operating as expected. Make sure that the tracker is receiving signals and transmitting information correctly.

To optimize your tracking experience, consider using the Trackar platform, which offers a one-time payment service, providing efficient management of your assets. Make the most of your Coban LK209C's functionalities!

SMS Commands

1. Device Setup Start

To start using the LK209C tracker, it is essential to perform the initial configurations. This ensures that the equipment functions correctly and meets your needs.

begin123456

2. Time Zone Configuration

Adjusting the time zone is crucial for ensuring that location information is recorded correctly. This helps in synchronizing tracking data.

time zone123456 0

3. Carrier APN Configuration

Configuring the APN (Access Point Name) is crucial for the device's communication with the carrier's network. APN, username, and password information must be entered correctly, as they vary according to the chip supplier and carrier.

apn,m2track.br,vivo,vivo#

apn123456 allcom.br

apn123456 allcom.vivo.com.br

apn123456 brt.br

apn123456 claro.com.br

apn123456 datatem.algar.br

apn123456 eseye.com

apn123456 gprs.amazoniacelular.com.br

apn123456 gprs.oi.com.br

apn123456 gprs.telemigcelular.com.br

apn123456 linksolutions.br

apn123456 m2data.algar.br

apn123456 m2data.arqia.br

apn123456 m2data.vivo.com.br

apn123456 m2m.vodafone.br

apn123456 m2mprepgago.br arqia arqia

apn123456 meta.vivo.com.br meta meta

apn123456 oktor.br

apn123456 sercomtel.com.br

apn123456 smart.m2m.vivo.com.br

apn123456 ss.algar.br

apn123456 tim.br

apn123456 tmdata.tim.br

apn123456 transmeet.br

apn123456 virtueyes.vivo.com.br

apn123456 voxter.algar.br

apn123456 voxter.br

apn123456 wap.ctbc.com.br

apn123456 wl.vivo.com.br

apn123456 y1.m2m.algar.com.br

apn123456 zap.vivo.com.br

Make sure to enter the correct APN to ensure device connectivity.

4. DNS and Port Configuration

It is necessary to configure the DNS servers and port so that the tracker can connect to the tracking server. This is vital to ensure that data is sent correctly.

SZCS,123456,DOMAIN=central.trackar.com.br:6013

5. Enable GPRS Transmission

Activating GPRS transmission is an essential step for the tracker to send location and status data in real-time.

gprs123456

6. Tracking Mode Configuration

Activating tracking mode allows the device to start monitoring and reporting its location. It is a fundamental setting for the tracker's operation.

tracker123456

7. Transmission Time Configuration

Set the time interval at which the tracker will send its information. In this case, the transmission time is set to 60 seconds.

upload123456 60

8. Vibration Alarm Activation

The vibration alarm is an important feature that allows detection of unwanted movements and alerts the user to potential security events.

shock123456

9. Sensor Sleep Mode Configuration

The tracker can enter hibernation mode after 5 minutes of inactivity. Any detected movement will reactivate the device, ensuring it is always ready for use.

sleep123456 shock

This mode can be activated through movement, SMS, or call.

Special commands

Special Commands

Here are some additional commands that can be used for specific functionalities of the tracker.

G123456

where

check123456

(s42,1234)

status

Param1

Param2

sos

sleep123456 10

sleep123456 shock

nosleep12345

shock123456

noshock123456

pwr1

pwr0

555

666

imei123456

rst

format
