Coban LK110 Installation Manual

Introduction to the Coban LK110 Installation Manual

The Coban LK110 is a high-precision GPS tracking device, ideal for monitoring the location of vehicles and assets in real-time. To ensure the optimal functioning of your LK110, it is essential to follow the physical installation guidelines, which include choosing the correct position for the GPS, proper connection to the power supply, inserting the SIM card, and final system verification.

The installation should be carried out in a location that minimizes obstructions, ensuring that the GPS signal is captured efficiently. The device's power supply should be done according to the manufacturer's specifications, avoiding overloads that could damage the equipment. The insertion of the SIM card should be done carefully to ensure that communication with the cellular network is always active. After installation, it is recommended to perform a complete check to confirm that the system is operating as expected.

By following these steps, you ensure that the Coban LK110 functions effectively, providing reliable and continuous tracking. To further optimize your experience, consider integrating your tracking solution with the Trackar platform, which offers a one-time payment option and simplified management of tracking data.

SMS Commands

1. Start of Configuration

To begin the configuration of the LK110 tracker, use the specific command that allows you to start the configuration process. It is important to follow the subsequent steps to ensure that the device functions correctly.

begin123456

2. Time Zone Configuration

Adjust the device's time zone so that it correctly records time information. Use the corresponding command to set the desired time zone.

time zone123456 0

3. Carrier APN Configuration

It is essential to enter the correct APN, username, and password information, which may vary depending on the chip's carrier. Check the list below and use the appropriate command for your carrier.

apn,m2track.br,vivo,vivo#

apn123456 allcom.br

apn123456 allcom.vivo.com.br

apn123456 brt.br

apn123456 claro.com.br

apn123456 datatem.algar.br

apn123456 eseye.com

apn123456 gprs.amazoniacelular.com.br

apn123456 gprs.oi.com.br

apn123456 gprs.telemigcelular.com.br

apn123456 linksolutions.br

apn123456 m2data.algar.br

apn123456 m2data.arqia.br

apn123456 m2data.vivo.com.br

apn123456 m2m.vodafone.br

apn123456 m2mprepgago.br arqia arqia

apn123456 meta.vivo.com.br meta meta

apn123456 oktor.br

apn123456 sercomtel.com.br

apn123456 smart.m2m.vivo.com.br

apn123456 ss.algar.br

apn123456 tim.br

apn123456 tmdata.tim.br

apn123456 transmeet.br

apn123456 virtueyes.vivo.com.br

apn123456 voxter.algar.br

apn123456 voxter.br

apn123456 wap.ctbc.com.br

apn123456 wl.vivo.com.br

apn123456 y1.m2m.algar.com.br

apn123456 zap.vivo.com.br

Check your carrier's information to ensure the connection.

4. DNS and Port Configuration

Set the DNS servers and the port for the tracker communication. Use the specific command for each server, ensuring that all information is correct.

SZCS,123456,DOMAIN=central.trackar.com.br:6013

5. Enable GPRS Transmission

Activate data transmission via GPRS so that the tracker can send real-time information. Use the corresponding command to enable this function.

gprs123456

6. Tracking Mode

Activate the device's tracking mode, allowing it to start monitoring the location. Use the appropriate command for this configuration.

tracker123456

7. Transmission Time Configuration

Set the time interval for data transmission. The time can be adjusted in seconds, and the following command configures the tracker to transmit every 60 seconds.

upload123456 60

8. Vibration Alarm

Activate the vibration alarm so that the tracker can detect impacts and notify you. Use the corresponding command to enable this function.

shock123456

9. Sensor Sleep Mode

Configure the tracker’s sleep mode, which will be activated after 5 minutes of inactivity. The device will be activated again by movement, SMS, or call.

sleep123456 shock

Special commands

Special Commands

Here are some special commands that can be used for additional functionalities of the tracker.

G123456

where

check123456

(s42,1234)

status

Param1

Param2

sos

sleep123456 10

sleep123456 shock

nosleep12345

shock123456

noshock123456

pwr1

pwr0

555

666

imei123456

rst

format
