CCTR CCTR-803 Installation Manual

Introduction to the CCTR CCTR-803 Installation Manual

In this manual, we present a detailed guide for the physical installation of the CCTR CCTR-803 GPS device. Proper installation of this equipment is crucial to ensure its full functionality and efficiency in tracking. To begin, it is essential to choose the ideal position for the GPS, which should be in a location where the signal can be received without obstructions, ensuring location accuracy.

Additionally, the power supply for the device must be done properly, using the power source recommended by the manufacturer. The installation of the SIM card also requires attention, as it is essential for communication between the device and the network. After completing these steps, it is important to conduct a thorough check to confirm that all components are functioning correctly.

The CCTR CCTR-803 is designed to provide a robust and reliable solution for tracking vehicles and assets. To further enhance the user experience, we suggest the Trackar platform, which offers a one-time payment system, making it easier to manage your GPS device without complications. Follow this manual and make the most of the functionalities of your CCTR CCTR-803!

SMS Commands

1. Factory Reset

To restore the tracker to factory settings, use the appropriate command. This is useful for troubleshooting or resetting the device to its original settings.

FACTORY*123456

2. Time Zone Configuration

Adjust the device's time zone to ensure that tracking data is accurate. The command should be sent with the desired time zone value.

TIMEZONE*123456*0

3. APN Configuration

APN configuration is essential for the device's communication with the network. Make sure to enter the correct information according to the carrier used. Each carrier may have specific values for APN, username, and password.

APN*123456*CLARO.BR

APN*123456*CLARO.COM.BR

APN*123456*GPRS.OI.COM.BR

APN*123456*SMART.M2M.VIVO.COM.BR

APN*123456*TIMBRASIL

APN*123456*ZAP.VIVO.COM.BR

USERNAME*123456*CLARO,CLARO

USERNAME*123456*OI,OI

USERNAME*123456*TIMBRASIL,TIMBRASIL

USERNAME*123456*VIVO,VIVO

Remember that APN information may vary depending on the carrier.

4. DNS and Port Configuration

It is necessary to configure the DNS servers and port to ensure that the tracker connects correctly to the network. This data is crucial for tracking functionality.

IP*123456*central.trackar.com.br,5040

5. Tracking Mode Configuration

Choose the tracking mode that best suits your needs. Mode 1 is the default and keeps the device always active, while Mode 2 activates the tracker only when in motion, saving battery.

MODE*123456*1

MODE*123456*2

In Mode 2, the tracker enters standby mode after 5 minutes of inactivity.

6. Upload Interval Setting

The upload interval determines how often the tracker sends data. The time can be adjusted between 30 and 999 seconds, with 30 being the factory default.

INTERVAL*123456*60

Special commands

Special Commands

These additional commands allow you to perform various useful functions on the tracker.

CHECK*123456

URL*123456

CHECKPHONE*123456

CHECKPASSWORD#

ALARM*123456

RESET*123456

KEEPONLINE*123456

SHOCKCONTROLGPRS*123456

FACTORY*123456

Use these commands to check settings, restart the device, and keep the connection active.
