Installation Manual for CCTR CCTR-801

Introduction to the Installation Manual for the CCTR CCTR-801

The CCTR CCTR-801 is a GPS tracking device designed to provide security and real-time control over your assets. Proper installation is essential to ensure the optimal performance of the equipment. In this manual, we will cover the essential steps for the physical installation of the CCTR-801, including the proper choice of GPS position, power connection, and SIM card installation.

The GPS position should be carefully selected to minimize obstructions and maximize signal reception. The power supply should be securely connected to ensure that the device operates continuously without interruptions. Additionally, checking the SIM card is crucial to ensure that the device is ready to operate on the correct network and that all functionalities are available.

Following these steps attentively will not only facilitate the installation but also ensure that the CCTR CCTR-801 operates at maximum efficiency. For even more effective control, consider integrating your device with the Trackar platform, which offers a one-time payment tracking system, making it easier to manage your assets practically and efficiently.

SMS Commands

1. Restore Factory Settings

To return the device to its original settings, use the appropriate command. This is useful for troubleshooting or resetting the tracker for new use.

FACTORY*123456

2. Set Time Zone

Adjust the device's time zone to ensure that tracking data is correct in relation to your location. The adjustment is made through a specific command.

TIMEZONE*123456*0

3. Configure Carrier APN

It is essential that the APN, username, and password settings are correctly adjusted, as they vary by carrier. Ensure you use the correct information to guarantee connectivity.

APN*123456*CLARO.BR

APN*123456*CLARO.COM.BR

APN*123456*GPRS.OI.COM.BR

APN*123456*SMART.M2M.VIVO.COM.BR

APN*123456*TIMBRASIL

APN*123456*ZAP.VIVO.COM.BR

USERNAME*123456*CLARO,CLARO

USERNAME*123456*OI,OI

USERNAME*123456*TIMBRASIL,TIMBRASIL

USERNAME*123456*VIVO,VIVO

Make sure to replace the APN, username, and password values according to the carrier used.

4. Set DNS and Port

To ensure that the tracker connects correctly to the network, it is necessary to configure the DNS servers and the port. Use the provided commands for this configuration.

IP*123456*central.trackar.com.br,5040

5. Select Tracking Mode

There are two tracking modes available. Mode 1 operates continuously, while Mode 2 activates the tracker only when in motion, saving battery. Choose the mode that best suits your needs.

MODE*123456*1

MODE*123456*2

Mode 2 may be more energy-efficient.

6. Set Upload Interval

The upload interval can be adjusted as needed, ranging from 30 to 999 seconds. A shorter interval provides more frequent updates, while a longer one saves battery.

INTERVAL*123456*60

Special commands

7. Special Commands

Here are some special commands that can be used to manage and check the operation of the tracker. These commands help keep the device running and troubleshoot issues.

CHECK*123456

URL*123456

CHECKPHONE*123456

CHECKPASSWORD#

ALARM*123456

RESET*123456

KEEPONLINE*123456

SHOCKCONTROLGPRS*123456

FACTORY*123456
