CCTR CCTR-620+ Installation Manual

Introduction to the CCTR CCTR-620+ Installation Manual

The CCTR CCTR-620+ is an advanced GPS tracking device designed to provide accuracy and reliability in locating vehicles and assets. This manual aims to guide you through the physical installation of your device, ensuring that all essential aspects are addressed for optimal operation.

In this section, we will discuss the proper position for installing the GPS, considering factors such as signal visibility and protection against interference. Powering the device is another critical point; you will learn how to connect it correctly to the vehicle's power source. Additionally, inserting the SIM card is a fundamental step to ensure the device communicates with the network.

Finally, an initial check will be presented, where you can confirm if the CCTR-620+ is functioning correctly and ready to be used. Proper installation of your tracker is essential to ensure that you make the most of the features offered by the CCTR CCTR-620+.

Also discover the Trackar platform, which offers a tracking solution with a one-time payment, further simplifying the management of your device.

SMS Commands

1. Factory Reset

To restore the device to factory settings, a specific command must be sent. This action will reset all custom settings and return the device to its original factory state.

FACTORY*123456

2. Time Zone Configuration

Adjusting the time zone is essential to ensure that the tracker correctly logs the times of activities. The following command should be used to set the desired time zone.

TIMEZONE*123456*0

3. Carrier APN Configuration

Configuring the APN is crucial for the proper functioning of the tracker. It is important to enter the correct APN, username, and password information, which vary according to the chip provider and the carrier used. Use the commands below to adjust the APN settings.

APN*123456*CLARO.BR

APN*123456*CLARO.COM.BR

APN*123456*GPRS.OI.COM.BR

APN*123456*SMART.M2M.VIVO.COM.BR

APN*123456*TIMBRASIL

APN*123456*ZAP.VIVO.COM.BR

USERNAME*123456*CLARO,CLARO

USERNAME*123456*OI,OI

USERNAME*123456*TIMBRASIL,TIMBRASIL

USERNAME*123456*VIVO,VIVO

Check your carrier's information before configuring.

4. DNS and Port Configuration

To ensure the tracker connects to the server, the DNS servers must be configured correctly. The commands below should be used to set the IPs and ports.

IP*123456*central.trackar.com.br,5040

5. Tracking Mode

The tracker can operate in different modes, depending on your needs. The default mode is Mode 1, which allows continuous operation, while Mode 2 activates a motion control that saves battery. Choose the mode that best meets your needs.

MODE*123456*1

MODE*123456*2

Mode 2 disables the tracker after 5 minutes of inactivity.

6. Upload Interval Setting

The upload interval determines how often the tracker will send data. The time can be adjusted between 30 and 999 seconds, with 30 being the factory default. Use the command below to set the desired interval.

INTERVAL*123456*60

Special commands

7. Special Commands

There are special commands that allow you to query and manage the tracker more efficiently. The commands below can be used to check settings, restart the device, and keep the tracker online.

CHECK*123456

URL*123456

CHECKPHONE*123456

CHECKPASSWORD#

ALARM*123456

RESET*123456

KEEPONLINE*123456

SHOCKCONTROLGPRS*123456

FACTORY*123456
