How to configure Concox GS503 tracker

The Concox GS503 tracker is a powerful tool for real-time monitoring and tracking. To ensure you make the most of this device's functionalities, it is essential to perform the correct setup. In this guide, we will cover the initial steps to configure your tracker, including setting up the APN, DNS server, and IMEI. Additionally, we will provide some tips on how to conduct tests to ensure everything is working perfectly.

Setting up the APN is crucial for your tracker to connect to the network. The DNS server also plays an important role in communication between the device and the monitoring platform. The IMEI, in turn, is the unique identification number of your tracker, and it is crucial for its operation.

After following the setup steps, we recommend conducting some tests to verify that the device is transmitting information correctly. This will ensure that you have real-time access to all the functionalities that the Concox GS503 offers.

For an even more complete tracking experience, consider using the Trackar platform, which offers a one-time payment service to manage your device conveniently and efficiently.

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This procedure is essential when you want to start a new configuration or troubleshoot.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Time Zone Configuration

Adjust the device's time zone to ensure that location data is accurate. The following command should be sent to make this configuration.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Configure Carrier APN

It is essential to update the APN, username, and password information according to the carrier of the used SIM card, as this information may vary. Use the commands listed below to configure.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. DNS and Port Configuration

To ensure proper communication of the device with the server, it is necessary to configure the DNS and the port. Use the following commands to set the correct parameters.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Sending Interval

Adjust the communication interval of the device, which can be configured in seconds. It is possible to set different parameters for ignition on and off. Below are the commands for the configuration.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

If the device uses an external battery, it is important to configure it correctly. Use the command below to set the necessary parameters.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

The global settings of the device can be adjusted through the appropriate command. This allows you to customize the operation of the device according to your needs.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

To activate the device's tow alarm, use the indicated command. This function is important to protect the vehicle against theft.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

If you need to know the current location of the device, use the command to request the position. This is useful for real-time monitoring.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

1. Special Commands

There are special commands that allow you to perform specific actions on the device. Below are some commands that can be used for additional functions.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
