How to configure the Teltonika FMB920 device via SMS

This guide shows how to connect the Teltonika FMB920 tracker to the platform using SMS commands. Send each command from the SIM card installed in the device, in the order indicated below.

SMS Commands

1. System Configuration

To configure the Teltonika device's system, use the appropriate command to adjust the desired settings. The configurations can be adjusted according to the user's needs, ensuring that the tracker operates efficiently.

setparam 100:1;107:2;109:10;110:0;106:1;112:0;102:3;101:1

2. GPRS Configuration - Server 01

The tracker must be configured to connect to a specific GPRS server. It is essential that the server information is correct to ensure effective communication between the tracker and the tracking platform.

setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:jbgprs.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:conectsys.br;2002:conectsys;2003:conectsys;2004:central.trackar.com.br;2005:6027;2006;1

3. GPRS Configuration - Server 02

Just like the first server, a second GPRS server must be configured to ensure redundancy and continuity of communication. The information must be entered correctly to avoid connection failures.

setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:hinova.br;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:m2data.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:datatem.algar.br;2002:datatem;2003:datatem;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:nlt;2003:nlt;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:iot4u.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1

4. GPRS Configuration - Server 03

Similarly to the previous servers, the third server must be configured. This is crucial to ensure that the tracker maintains communication even if one of the servers fails.

setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:smart.m2m.vivo.com.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:transmeet.br;2002:transmeet;2003:transmeet;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:allcom.vivo.com.br;2002:allcom;2003:allcom;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:voxter.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:m2data.arqia.br;2002:arqia;2003:arqia;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:jbgprs.algar.br;2002:algar;2003:algar;2004:central.trackar.com.br;2005:6027;2006;1

setparam 2001:upchip.br;2002:vivo;2003:vivo;2004:central.trackar.com.br;2005:6027;2006;1

5. Data Acquisition

Data collection is essential for the operation of the tracker. Configure the data acquisition parameters to ensure that information is collected accurately and at appropriate intervals.

setparam 10000:3300;10100:3300;10200:3300;10050:10;10150:10;10250;10051:100;10151:100;10251:100;10050:30;10152:30;10252:30

6. Accelerometer Settings

The functionalities of the accelerometer must be configured so that the device can respond to movements and changes in position. This is crucial for detecting security events.

setparam 11400:2;11500:2;11406:2

Special commands

Special Commands

Special commands allow additional interactions with the device, such as rebooting, locking, and formatting, providing greater control and maintenance of the tracker.

cpureset

getstatus

getgps

ggps

getimeiccid

getimsi

setdigout 1

setdigout 0

sdformat

deleterecords

defaultcfg
