How to configure the MXT T1 device via SMS
This guide shows how to connect the MXT T1 tracker to the platform using SMS commands. Send each command from the chip installed in the device, in the order indicated below.
SMS Commands
1. Carrier APN Configuration
The correct APN configuration is essential to ensure that the tracker functions properly. It is important to replace the APN, username, and password fields with the correct information, as they vary according to the chip provider and carrier. Here are the necessary commands for different servers:
0000,XXXXXXX,2,1,claro.com.br,claro,claro,central.trackar.com.br,5020,central.trackar.com.br,5020
0000,XXXXXXX,2,1,linksolutions.br,link,link,central.trackar.com.br,5020,central.trackar.com.br,5020
0000,XXXXXXX,2,1,smart.m2m.vivo.com.br,vivo,vivo,central.trackar.com.br,5020,central.trackar.com.br,5020
0000,XXXXXXX,2,1,transmeet.br,transmeet,transmeet,central.trackar.com.br,5020,central.trackar.com.br,5020
0000,XXXXXXX,2,1,voxter.br,algar,algar,central.trackar.com.br,5020,central.trackar.com.br,5020
0000,XXXXXXX,2,1,voxter.br,nlt,nlt,central.trackar.com.br,5020,central.trackar.com.br,5020
2. Transmission Interval Definition
The transmission interval should be configured to optimize battery consumption and tracker efficiency. The default is 60 seconds with the ignition on and 55 minutes (3300 seconds) with the ignition off. This configuration can be adjusted as needed.
0000,XXXXXXX,4,60,3300,10,1,5,10
3. Position Request via GPRS
To request the device's position via GPRS, use the corresponding command. This is useful for monitoring the location in real-time.
0000,XXXXXXX,7
After configuration, it is recommended to test the commands to ensure everything is working correctly.
Special commands
4. Special Commands
Here are the special commands that can be used to lock or unlock the device.
0000,XXXXXXX,5,1,0,0
01A633000000002010211021B96904
0000,XXXXXXX,5,0,0,0
01A6330000000020102100987904
Remember to replace 'XXXXXXX' with the last 7 digits of the device ID.
