How to configure the MT Topten MT05 device via SMS

This guide shows how to connect the MT Topten MT05 tracker to the platform using SMS commands. Send each command from the chip installed in the device, in the order indicated below.

SMS Commands

1. DNS and Port Configuration

It is essential to use a domain DNS to ensure the correct communication of the device. The recommended servers are as follows: for all cases, use the same address. Server 01, 02, and 03 should be configured to the same URL, which is central.trackar.com.br on port 6216.

SET URL=central.trackar.com.br:6216

2. Carrier APN Configuration

The APN configuration is crucial and must be adjusted according to the carrier used. Each carrier may have a specific APN name, username, and password. Make sure to enter the correct information to ensure the device's connectivity.

SET APN=ALLCOM.BR:ALLCOM:ALLCOM

SET APN=JBGPRS.ALGAR.BR:ALGAR:ALGAR

SET APN=META.COM.BR:VIVO:VIVO

SET APN=SMART.M2M.VIVO.COM.BR:VIVO:VIVO

SET APN=TRANSMEET.BR:TRANSMEET:TRANSMEET

3. Communication Time Adjustment with Ignition On

The communication time with the ignition on can be configured in seconds. The default interval of 60 seconds is recommended for regular data transmission. Adjust as needed to meet your requirements.

SET T3 FREQ=060

4. Communication Time Adjustment with Ignition Off

Similarly, the communication time with the ignition off is configurable in minutes. An interval of 55 minutes is suggested to save battery while the vehicle is not in use. Adjust as necessary.

SET HEARTBEAT=55

These settings are recommended to optimize the performance of the tracker.

Special commands

5. Special Commands

Special commands allow you to manage and obtain information from the device efficiently. Use them as needed to monitor and configure the tracker.

GET NTW

GET INFO

GET PROG

GET LOCATION

SET SLEEP_MODE=1

WAKE_UP

SET IGNITION_DETECTION=0

SET ENGINEV=13200

GET IGNITION_DETECTION

SET RELAY=1

SET RELAY=0

REBOOT
