How to configure the Concox IB-GT102 device via SMS

This guide shows how to connect the Concox IB-GT102 tracker to the platform using SMS commands. Send each command from the SIM card installed in the device, in the order indicated below.

SMS Commands

1. Factory Reset

To restore the device to factory settings, use the appropriate command. This is essential when you want to reset the device's settings to an original state.

AT+GTRTO=gv55,4,,,,,,FFFF$

2. Set Time Zone

Adjust the device's time zone using the specific command. It is important that the time zone is correct for accurate tracking.

AT+GTTMA=gv55,+,0,0,0,,,,,,FFFF$

3. Set Carrier APN

Configuring the APN is crucial to ensure that the device connects correctly to the carrier's network. APN, username, and password information varies according to the chip provider and carrier used. Make sure to enter the correct data.

AT+GTBSI=gv55,agilis.algar.br,agilis,agilis,,,,,FFFF$

AT+GTBSI=gv55,allcom.br,allcom,allcom,,,,,FFFF$

AT+GTBSI=gv55,datacard.nextel3g.net.br,,,,,,,FFFF$

AT+GTBSI=gv55,jbgprs.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,linksolutions.br,link,link,,,,,FFFF$

AT+GTBSI=gv55,m2data.arqia.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,m2data.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,meta.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,smart.m2m.vivo.com.br,vivo,vivo,,,,,FFFF$

AT+GTBSI=gv55,ss.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,ss.br,arqia,arqia,,,,,FFFF$

AT+GTBSI=gv55,tim.br,tim,tim,,,,,FFFF$

AT+GTBSI=gv55,transmeet.br,transmeet,transmeet,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,algar,algar,,,,,FFFF$

AT+GTBSI=gv55,voxter.algar.br,nlt,nlt,,,,,FFFF$

4. Set DNS and Port

It is necessary to define the DNS server and port to ensure proper communication of the device with the tracking servers. Make sure that the details are correct.

AT+GTSRI=gv55,4,,2,central.trackar.com.br,5023,,,,0,0,0,1,,,FFFF$

5. Send Interval

The data send interval can be adjusted as needed. You can configure both the time in seconds and the angle in degrees for the device, allowing customization according to user needs.

AT+GTFRI=gv55,1,0,,0,0000,0000,,60,200,1000,,20,3300,,,,,FFFF$

6. External Battery Configuration

The external battery configuration must be performed to ensure that the device functions correctly, especially in situations where the main power source may be interrupted.

AT+GTEPS=gv55,2,1000,28000,2,3,0,0,0,0,1,30,30,,FFFF$

7. Global Settings

Global settings allow you to customize various aspects of the device, such as sending frequency and activating specific functions. It is crucial that these settings are adjusted according to the intended use.

AT+GTCFG=gv55,gv55,,1,0,,,3F,2,,1F2F,1,1,1,120,2,1,1,1,1F,0,FFFF$

8. Enable Tow Alarm

Activating the tow alarm is an additional safety measure that can alert the user in case of unauthorized movement of the vehicle.

AT+GTTOW=gv55,1,5,1,60,0,0,0,0,2,3,2,,,,,,,,,FFFF$

9. Request Position

The command to request the device's position is essential to obtain real-time information about the vehicle's location.

AT+GTRTO=gv55,1,,0,,,,FFFF$

Special commands

Special Commands

Below are special commands that can be used for various additional functions of the device.

AT+GTRTO=gv55,3,,,,,,FFFF$

AT+GTHMC=gv55,1,00000:00:00,,,,,,,,,FFFF$

AT+GTRTO=gv55,D,,,,,,FFFF$

AT+GTRTO=gv55,0,,0,,,,FFFF$

AT+GTRTO=gv55,7,,0,,,,FFFF$

AT+GTJDC=gv55,2,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTJDC=gv55,0,25,,5,10,10,,0,0,0,0,,FFFF$

AT+GTOUT=gv55,1,0,0,0,0,0,,,,0,,,,,,,FFFF$

AT+GTOUT=gv55,0,0,0,0,0,0,,,,0,,,,,,,FFFF$
