How to configure the Coban TK905 device via SMS
This guide shows how to connect the Coban TK905 tracker to the platform using SMS commands. Send each command from the SIM card installed in the device, in the order indicated below.
SMS Commands
1. Start Equipment Configuration
To initiate the configuration of the tracker, you must send the initial command. This allows the device to start accepting subsequent settings.
begin123456
2. Set Time Zone
Adjust the time zone of the tracker to ensure that location data is correct in relation to local time. Use the appropriate command to set the desired time zone.
time zone123456 0
3. Configure Carrier APN
Configuring the APN (Access Point Name) is crucial for the tracker's connectivity. Make sure to enter the correct APN, username, and password information, which varies according to the carrier used.
apn123456 allcom.br
apn123456 linksolutions.br
apn123456 m2data.arqia.br
apn123456 smart.m2m.vivo.com.br
apn123456 tim.br
apn123456 transmeet.br
apn123456 virtueyes.com.br
apn123456 zap.vivo.com.br
4. Set DNS and Port
To ensure the tracker works correctly, it is necessary to configure the DNS servers and corresponding ports. Enter the required information for these fields.
Server 01, Server 02, Server 03: details to be filled in.
5. Activate Vibration Alarm
Activate the vibration alarm of the tracker so that it can detect any unwanted movement. This configuration is essential for the device's security.
shock123456
6. Activate Tracking
Enable the tracking function of the device. This will allow you to locate the tracker in real-time.
tracker123456
7. Activate GPRS Transmission
For the tracker to send location data, it is necessary to activate transmission via GPRS. Use the corresponding command for this configuration.
gprs123456
8. Set Transmission Time
Adjust the time interval for data transmission while the tracker is in motion. The default is 60 seconds, but it can be adjusted as needed.
upload123456 060
Adjustable time.
9. Sleep Mode by Sensor
The tracker enters sleep mode after 5 minutes of inactivity. It will be activated again upon detecting any movement, vibration, or call. This function helps to save battery.
sleep123456 shock
Wake-up mode: Movement, SMS or CALL.
Special commands
10. Special Commands
Here are some additional commands that can be used to manage the tracker more effectively.
G123456#
where
gprs123456 0
sensitivity123456 + selecionar número 1, 2 ou 3!
check123456
speed123456 080
nospeed123456
shock123456
noshock123456
lowbatsms123456 on
sleep123456 time
sleep123456 shock
sleep123456 off
imei123456
reset123456
